Storage Unit - Four Cubes
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
C
x20
x8
x20
E
F
G
H
x4
x12
x2
x4
Hardware Supplied
Phillips & Flathead screwdriver required
mocka.co.nz | mocka.com.au
W
D
Safety
Strap
x4
X
I
J
wall
anchor
x1
x20
x2
washer
Wall Strap
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
WARNING:
Any furniture that is not anchored to a wall has the potential to
tip over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that
all furniture is anchored to a wall. We supply a free safety wall anchor with
all furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please
note that different wall materials may require different fixing devices from
Wall
Screw
Y
r/washer
screw
x1
Z
x1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mocka Four Cubes
Summary of Contents for Mocka Four Cubes
- Page 1 Storage Unit - Four Cubes Assembly Instructions Thank you for your purchase. Please follow the instructions below for correct assembly. WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
- Page 2 Storage Unit - Four Cubes Assembly Instructions First screw in hardware (B) into side panels [1] and [3]. Slide both Tighten (A) with a screwdriver. Slide cupboard back panel [6] into panels together with the middle shelves [2] and [4], making sure the grooves as shown.
- Page 3 Storage Unit - Four Cubes Assembly Instructions Screw in hardware (B) into base panel [8]. Place base panel on top Attach feet blocks (D) to base panel using long screws (C) and the while sliding the ends of (B) into holes on the top of the side panels.
- Page 4 Storage Unit - Four Cubes Assembly Instructions Flip Four Cube over so feet stand on the floor. Slide cupboard back Screw in hardware (B) into top panel [5]. Place panel on top of side panel [6] into grooves as shown. Screw hinge pins (F) into the holes in panels while sliding the ends of (B) into the holes.
- Page 5 Storage Unit - Four Cubes Jolt Wardrobe Assembly Instructions ASSEMBLY INSTRUCTIONS Fasten clip plate (E) to the cupboard door using screws (H). Attach the Use stickers (J) to cover the holes where the hardware (A) is used. magnetic clip (I) inside the cupboard using screws (G). Check door closes.
- Page 6 Storage Unit - Four Cubes Assembly Instructions Wall Mount Strap Washer wall anchor wall screw wall screw Attach the safety strap (W) to the top of the back side of the unit using Once assembled lift furniture into place, do not drag. Use a drill to create screw (Y).
