Park Scale Models AT-17 Bobcat Assembly Manual page 5

12. Fit and glue FL10 into the center notches of F2 &
F3. Fit and glue FL9, FL8 and FL7 into the notches
in F2 & F3 on both sides of FL10.
13. Slide this assembly onto the wing mount/battery
box assembly as shown, do not glue in place!
14. Fit and glue FL1 into the center notch of F3,
unsure that the notch in FL1 is facing up. Fit and
glue FL2 and FL3 on both sides of FL1 as shown.
15. Fit and glue F1 to the wing mount/battery tray
assembly first. Carefully align and fit FL1-FL10 into
the notches in F1, ensure that they are fully
inserted into the notches and then glue in place.
Glue F2 and F3 to the wing mount/battery box
assembly.
FL2
FL1
FL3
F1
FL10
FL9
FL8
FL7
