20. Fit R3A in place.
21. Fit and glue LE1 to R3A-R14. Sand LE1 to match
the top and bottom contours of the wing ribs.
LE1
22. Trim the excess sheeting along R3.
23. Glue the bottom sheeting to R3-R14 and LE1.
