1. Fit and glue the cowl formers CF1 and CF2
together. Epoxy ¼" magnets into CF2 where
indicated. Ensure that the polarity of the magnets
in CF2 match the polarity of the magnets in the
nacelle.
2. Fit and glue six (6) CL to CF2 as shown.
3. Fit and glue CF1 to the six CL as shown.
Cowl Construction
CF1
¼" magnets
CF2
CL
CF2
CF1
