EtherWAN EL9100 Quick Start Manual

This quick start guide describes how to install and use the Gigabit hardened media converter. This is the media converter of choice for harsh
environments constrained by space.

Physical Description

The Terminal Block and Power inputs
•
DC Terminal Block Power Inputs: There are two pairs of power inputs can be used to power up this device.
•
DC JACK Power input: 12VDC.

DIP Switch

DIP switch No. 0 (OFF)
The 1000Base-T and 1000Base-SX/LX/BX Connectors
The 1000Base-T Connections
The following lists the pinouts of 1000Base-T port.
The 1000Base-SX/LX Connections
The fiber port pinouts
The Tx (transmit) port of device I is connected to the Rx (receive) port of device
II, and the Rx (receive) port of device I to the Tx (transmit) port of device II.
The WDM 1000Base-BX Connections
The fiber port pinouts
Only one single-mode optical fiber is required to transmit and receive data.
Gigabit Hardened Media Converter
Power Input Assignment
Power3
Power2
Power1
Relay Alarm Assignment
FAULT
1 Disable LFPT
2 Disable link down alarm for copper port Enable link down alarm for copper port
3 Disable link down alarm for fiber port
4 Enable force mode for fiber port
12VDC DC Jack
＋
12-48VDC
－
Power Ground
＋
12-48VDC
Terminal Block
－
Power Ground
Earth Ground
*Relay warning signal disable for following:
1. The relay contact closes if Power1 and
Power2 are both failed but Power3 on.
2. The relay contact closes if Power3 is failed
but Power1 and Power2 are both on.
1 (ON)
Enable LFPT
Enable link down alarm for fiber port
Enable auto-negotiation for fiber port
1 V1
