EL2326 OAM Managed 10/100/1000BASE-TX to
100/1000BASE-X Dual Rate Media Converter

FCC Warning

This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with this user's guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the user
may be required to take adequate measures.
All brand names are registered trademarks of their relative
holders.
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL2326 and is the answer not in the manual?

Questions and answers

Related Manuals for EtherWAN EL2326

Summary of Contents for EtherWAN EL2326

  • Page 1: Fcc Warning

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 2: Preface

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Preface This OAM Managed Dual Rate Media Converter can be monitored and configured through management via SNMP and Web-based. This manual describes how to install and use the OAM Managed Dual Rate Media Converter. The OAM...

  • Page 3: Table Of Contents

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Table of Contents FCC W ............1 ARNING CE M ..........1 ARNING ..............2 REFACE ..........3 ABLE OF ONTENTS ............4 NTRODUCTION ........4 RODUCT VERVIEW ........4...

  • Page 4: Introduction

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Introduction The OAM Managed Dual Rate Media Converter provides one channel for media conversion between 10/100/1000Base-TX to 100Base or 1000Base dual rate fiber interface. Product Overview Product Features  Complies with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.3ab 1000Base-T, and IEEE802.3z 1000Base-SX/LX.

  • Page 5: Packing List

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Down Disable LFPT Enable LFPT Enable Auto-Negotiation for TX Enable Force mode for TX port port TX port Force mode: Full- TX port Force mode: Half- duplex duplex TX port Force mode: 100Mbps...

  • Page 6: One -Channel Mediac

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter One-Channel Media Converter Ports This converter provides one TX port and one dual rate 100Base-FX/BX or 1000Base-SX/LX/BX fiber interface. For the dual rate 100Base-FX/BX or 1000Base-SX/LX/BX fiber interface, it provides options of multi-mode/single-mode or WDM multi-mode/single-mode fiber.
  • Page 7 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter LEDs State Indication POWER Steady Power on Power off OAM LOOP Test Blink when testing and light in 3 seconds if pass pass Test fail Blink when testing and until if fail...

  • Page 8: Installation

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Installation This chapter gives step-by-step installation instructions for the Converter. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference.
  • Page 9 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Cable management tray, board of cable outlet hole, and cable outlet hole. Route the fiber cable. Bend the board of cable outlet hole. User’s Manual...

  • Page 10: Connecting To Power

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Cable ties. Connecting to Power  This Converter is a plug-and-play device.  Connect the supplied AC to DC power adaptor to the receptacle on the front panel of the converter, and then attach the plug into a standard AC outlet with a voltage range from 100 to 240VAC.

  • Page 11: System Configuration

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter System Configuration This chapter provides network managers and system administrators with information about how to configure the OAM Managed Dual Rate Media Converter via the Web Browser. Logging on to the Media Converter The default IP Address for the OAM Managed Media Converter is 192.168.1.10.

  • Page 12: Network Information

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Network Information User’s Manual...

  • Page 13: Local Setting

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter It will show local device information and local port status. Local Setting IP Configuration  DHCP Client: Click “DHCP Client” drop-down menu to choose “Disable” or “Enable” from the “DHCP Client” drop- down list to disable or enable DHCP Client setting for the media converter.
  • Page 14 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  Gateway: Click in the “Gateway” text box and type a new address to change the Gateway.  Description: Click in the “Description” text box and type a description for the media converter. Description field can only be a number, in English, or “*@_-“.
  • Page 15 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  New Password: Click in “New Password” text box and type a new password.  Confirm: Click in “Confirm” text box and type the new password in “Confirm” text box again to verify it.
  • Page 16 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Fault-Pass-Through) then to enable Remote Fault Detect and Link Loss Carry Forward.  Remote Fault Detect: The media converter will set local UTP port link up or link down according to remote device’s UTP port link status if enable this function.
  • Page 17 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  Mode: The mode of TP port can be set by DIP Switch inside media converter. Click “Mode” drop-down menu to choose “Auto Speed”, “1000 Full”, or “100 Full” from the “Mode”...
  • Page 18 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  Egress Rate Limit (kbps): Click “Egress Rate Limit” drop- down menu to choose the egress rate limit from the “Egress Rate Limit” drop-down list for TP or FX port. Or click “Egress Rate Limit”...
  • Page 19 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter This page shows local device’s MIB counters.  Clear: All MIB counters will be cleared to zero if click “Clear” button.  Refresh: Click “Refresh” button to show the current MIB counters again.
  • Page 20 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  SNMP Trap IP Address: Click in “SNMP Trap IP Address” text box and type SNMP server’s IP address used for trap destination IP.  Apply: Click “Apply” button when you finished SNMP Configuration.
  • Page 21 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter SNMP Write Community:  Add Write Community: Click in “Add Write Community” text box and type a write community name.  Click in “Delete Write Delete Write Community: Community” text box and type a write community name to be deleted.
  • Page 22 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  VLAN Mode: Click “VLAN Mode” drop-down menu to choose “Disable” or “Enable” from the “VLAN Mode” drop- down list to disable or enable 802.1Q VLAN Group. User could set 16 VLAN entries if enable 802.1Q VLAN Group functions.
  • Page 23 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Remove Tag: The media converter will remove VLAN tags from packets if they are tagged when these packets are output. The media converter will not modify packets received without tags.
  • Page 24 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  Q in Q Enable: Click “Q in Q Enable” drop-down menu to choose “Disable” or “Enable” from the “Q in Q Enable” drop-down list to disable or enable Q in Q function.

  • Page 25: Remote Setting

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  Apply: Click “Apply” button when you finished VLAN Group setting. Web connection may be lost because of the VLAN tag if Q-in- Q is enabled. Remote Setting 802.3ah Functions 802.3ah Configuration:...
  • Page 26 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Loopback Test:  Send Packet Number (1~255): Click in “Send Packet Number” text box and type packet number to be sent.  Packet Length (Not include CRC) (60~1514): Click in “Packet Length”...
  • Page 27 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter User’s Manual...

  • Page 28: Tools

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter This page shows 802.3ah Status Information of the media converter. Tools System Reboot  OK: Click “OK” button to restart the media converter.  OK: Click “Cancel” button to cancel the media converter restarting.
  • Page 29 EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter  SaveToFlash: Click “SaveToFlash” button to save all current configurations to media converter as backup.  LoadFromFlash: Click “LoadFromFlash” button to restore to previous backup configuration. The Web Interface may be disconnected for restoration.

  • Page 30: Logout

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Logout  OK: Click “OK” button to logout of the media converter.  OK: Click “Cancel” button to cancel the media converter logout. Reset Button There is a reset button located on the PCB board as shown in picture below.

  • Page 31: Specifications

    EL2326 OAM Managed 10/100/1000BASE-TX to 100/1000BASE-X Dual Rate Media Converter Specifications Applicable Standards IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX/LX Fixed Ports 1 10/100/1000Base-TX port 1 dual rate 100Base-FX/BX or 1000Base- SX/LX/BX fiber interface 1 100Base and 1000Base dual rate SFP fiber...
