YASKAWA AC Drive A1000 Option
120 Vac Digital input
Installation Manual
Type: DI-101
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end
user receives this manual.
E(G) HC H1 H2 DM+ DM- IG R+ R- S+ S-
V+ AC V- A1 A2 A3 FM AM AC MP RP AC
S1 S2 S3 S4 S5 S6 S7 S8 SN
S1 S2 S3 S4 S5 S6 S7 S8 SN
MANUAL NO. TOEP YEAOPT 07
M3 M4 M6
M1 M2 M5
MA MB MC
SC SP
1
2
3
4
5
6
7
8
9
10
11
Advertisement
Related Manuals for YASKAWA DI-101
Summary of Contents for YASKAWA DI-101
- Page 1 YASKAWA AC Drive A1000 Option 120 Vac Digital input Installation Manual Type: DI-101 To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance. Ensure the end user receives this manual. E(G) HC H1 H2 DM+ DM- IG R+ R- S+ S-...
- Page 2 Yaskawa. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
-
Page 3: Table Of Contents
7 SPECIFICATIONS ....... . . 22 YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual... -
Page 4: Preface And Safety
The selection and application of Yaskawa products remain the responsibility of the equipment manufacturer or end user. Yaskawa accepts no responsibility for the way its products are incorporated into the final system design. Under no circumstances should any Yaskawa product be incorporated into any product or design as the exclusive or sole safety control. - Page 5 Indicates a hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. NOTICE Indicates an equipment damage message. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 6 • When ordering new copies of the manual, contact a Yaskawa representative or the nearest Yaskawa sales office and provide the manual number shown on the front cover.
-
Page 7: Product Overview
◆ About this Product The DI-101 option has eight optically isolated input terminals that can be used to connect external 120 Vac control circuitry to the A1000 drive. The DI-101 option mounts directly to the A1000 control board terminals (S1 to S8 and SN). This option makes it possible to control the A1000 digital inputs with 120 Vac. -
Page 8: Receiving
• A straight-edge screwdriver (blade depth: 0.4 mm, width: 2.5 mm) is required to wire the option terminal block. Note: Tools required to prepare option cables for wiring are not listed in this manual. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual... -
Page 9: Option Components
<1> Multi-function Input <1> Multi-function Input <1> Common Control Input Common Common (spare) Control Input Common <1> Terminal functions S1 to S8 may change based on drive programming. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual... -
Page 10: Installation Procedure
Do not touch circuit boards while the power to the drive is on. Failure to comply could result in death or serious injury. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual... - Page 11 Check wiring to ensure that all connections are correct after installing the option and connecting any other devices. Failure to comply may result in damage to the option. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 12 B – DI-101 Option E – A1000 TB1 - Digital Input Terminal Block, Insertion Point for DI-101 Option C – Cover Screw Figure 2 Drive Components with Option YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 13 NOTICE: Damage to Equipment. Observe proper electrostatic discharge procedures (ESD) when handling the option, drive, and circuit boards. Failure to comply may result in ESD damage to circuitry. Figure 3 Figure 3 Terminal Cover Removal YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 14 When handling, always hold the board from the edges and do not touch the components. Before installing this option, a technically qualified individual, familiar with this type of equipment and the hazards involved, should read this entire installation guide. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 15 5 Installation Procedure Insert the DI-101 option (B) into the A1000 drive control terminals TB1, S1 to S8 and SN at the insertion point (E). Refer to Figure 6 for the proper placement of the option terminals into the drive TB1 terminals.
- Page 16 If no wire jumper is present, prepare and install a jumper according to Figure Route the customer-supplied option wiring through one of the cable glands on the A1000 drive bottom conduit bracket. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 17 5 Installation Procedure Prepare the external 120 Vac control circuit wires (customer supplied) for terminals S1 to S8 and X2 on the DI-101 option as shown in Figure Figure 7 Preparing wire ends: Screwdriver blade size Strip wire insulation about 5.5 mm and lightly twist the end with fingers, keeping the ends from fraying.
- Page 18 S8 External baseblock 3 mm Isolation 120 Vac Figure 8 Wiring Diagram Example To ensure accurate control, use a stable 120 Vac power supply for the DI-101 input voltage source. YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 19 5 Installation Procedure Replace terminal cover (D) and secure screw (C). Figure 9 Figure 9 Replace the Terminal Cover YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
- Page 20 0.34 (22 AWG) AI 0.34 - 6TQ 10.5 (13/32) 0.8 (1/32) 2 (5/64) 6 mm 0.5 (20 AWG) AI 0.5 - 6WH 14 (9/16) 1.1 (3/64) 2.5 (3/32) YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual...
-
Page 21: Troubleshooting
TB1 terminals SC to SP. • Verify the signal is present at the DI-101 option input terminals by using an AC voltmeter to measure for a 120 Vac input signal is present on any activated terminals S1 thru S8 with respect to the X2 terminal. -
Page 22: Specifications
Date of original publication Date of publication Date of Revision Section Revised Content Publication Number August 2018 Pg. 16, Cover Corrected M4/M6 terminal designations May 2011 First edition YASKAWA TOEP YEAOPT 07 A1000 Option DI-101 120 Vac Interface Installation Manual... - Page 24 YASKAWA AC Drive A1000 Option 120 Vac Digital input Installation Manual YASKAWA AMERICA, INC. 2121, Norman Drive South, Waukegan, IL 60085, U.S.A. Phone: 1-800-YASKAWA (927-5292) or 1-847-887-7000 Fax: 1-847-887-7310 http://www.yaskawa.com DRIVE CENTER (INVERTER PLANT) 2-13-1, Nishimiyaichi, Yukuhashi, Fukuoka, 824-8511, Japan Phone: 81-930-25-3844 Fax: 81-930-25-4369 http://www.yaskawa.co.jp...
