UNIT 2
Operation, cont.
Manual Reference Method-
The Micro can be used to certify fiber links (shown in detail in the next unit) or to measure link loss by setting a manual reference. The
manual reference method is used to measure the actual loss in a fiber link, and it is recommended that only those users who are very
familiar with calculating link budgets should use this method.
1) From Immediate Mode, press
2) At the MAIN MENU, press
continue.
3) Press
F2
to LOAD the selected link, and press
4) From the MAIN MENU, press
this method will overwrite any previous certification or manual references.
5) Press
F1
to scroll through the wavelengths, and press
wavelength.
6) Type in the manual reference using the keypad, and press
7) Press to return to Immediate Mode and TAKE READINGS. Data storage is covered in more detail in the next unit.
3
recommended for advanced users only
MENU
to enter the MAIN MENU.
1
to SELECT LINK. Highlight a link, and press
DONE
to continue.
2
to DEFINE LINK. Press
METER FUNCTIONS
F3
to change the name and/or date. Press
2
to SET A MANUAL REFERENCE.
F2
to set the manual reference. The asterisk shows the currently selected
DONE
to continue. Press
2-4
NOTE: setting a reference with
DONE
to return to the MAIN MENU.
DONE
to
