UNIT 2
Operation, cont.
Stored Data Menu
The STORED DATA menu allows the user to manipulate data that is stored in the MicroMeter.
<1>VIEW/EDIT/LOAD
MicroMeter. The VIEW/EDIT/LOAD screen initially loads with the first data point stored in memory. To go to a different data point, use:
F1
to scroll through the fiber names;
wavelengths for the currently selected data point.
Pressing will LOAD the selected data point, and return the user to Immediate Mode showing the selected data point. From there, the
0
user can continue saving data from that point.
Pressing will EDIT (or reshoot) the selected data point. The user will be returned to Immediate Mode to re-save the data point. After
5
the data point is re-saved, the user is returned to the last data point that was previously stored.
<2>PRINT RANGE
The printout is formatted in an easy-to-read format.
<3>DELETE RANGE
should only be done after the data points have been downloaded into the PC with Reporter software.
<4>DOWNLOAD DATA
downloaded to a terminal program is in a Comma-Delimited format for easy placement into a program that can format Comma-
Delimited files. The PC must be connected to the meter via the MicroMeter download cable.
If the user is downloading to Reporter, then no further action is necessary from this screen. Reporter will handle the data transfer.
If the user is downloading to a terminal program, then the user must start the terminal program, and press
Power OFF
Press
OFF
to shut down the MicroMeter. The user will be prompted to verify shutdown.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - FAX 781.665.0780 - TestEquipmentDepot.com
- this option allows the user to view, edit, or load any data point that was previously stored in the
F2
to scroll through the fiber runs for the currently selected fiber name; or
- this option allows the user to print data points to a serial device, such as a serial printer or terminal program.
- this option allows the user to delete a range of data points, or delete all of the data points from the meter. This
- this option allows the user to download data either to Reporter software, or to a terminal program. Data
METER FUNCTIONS
F3
to scroll through the
F1
to begin the download.
