Shampoo Chair MIRAKU
Product Code
Shampoo Chair
●
[Long Legrest Type]
SC-S81XL
SC-S81XM
[Legrest Type]
SC-S81LL
SC-S81LM
[Step Type]
SC-S81SL
SC-S81SM
Operating Manual
（Image is of SC-S81LM Legrest Type）
Thank you for purchasing Takara Belmont product.
The instructions contained in this
booklet should be thoroughly read and
understood before use.
This product is an industrial shampoo unit designed
for barbers and hair salons. Only use this product for
its intended purpose and do not use it for
non-hairdressing work.
Keep this manual and refer back to it when
required.
SC-S81XH
SC-S81LH
SC-S81SH
2023.07
1A0JN4A0
Ver.2
Table of Contents
２
６
７
７
７
８
９
９
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takara Belmont MIRAKU SC-S81XL
Summary of Contents for Takara Belmont MIRAKU SC-S81XL
-
Page 1: Table Of Contents
Maintenance １６ Daily Inspections １６ （Image is of SC-S81LM Legrest Type） Before Requesting Repairs １６ Thank you for purchasing Takara Belmont product. Specification １７ The instructions contained in this Standard Period of Use １８ booklet should be thoroughly read and understood before use. -
Page 2: Safety Precautions
These precautions are important for ensuring safety. Adhere to these precations at all times. Takara Belmont is not responsible for any damage or risk to the person using this product or those around them due to accidents if this product is used without adhering to the “Safety Precautions”... - Page 3 Warning Ground items properly. Adhere to the following when handling power plugs. ● E n s u r e t h a t t h i s p r o d u c t i s t h e o n l y a p p l i a n c e Ground c o n n e c t e d t o t h e o u t l e t .
- Page 4 Warning Due to the mechanism of the chair, there is a gap around the movable parts. Touching metallic parts of the inner part of the chair from this gap may result in cutting hands or fingers or pinching injury while operation, leading to serious injury. Especially, hands and fingers of small children may easily be trapped by the gap, and will be more likely to cause a serious injury. We shall ask salon workers and parents to pay maximum attention to avoid such danger. A serious injury may happen in the following cases. Pinched by the movable part. Customer or equipment may fall. Pinched by the movable part.
- Page 5 Warning Do not apply load with the legrest raised. Be careful not to touch the switches during shampooing. Do not get on or apply load to the legrest when it is in the raised Take care not to accidentally operate the foot switch or manual switch, or trip over the foot switch or base part during shampooing position.
-
Page 6: Precautions For Use
Precautions for Use People only allowed to sit in the chair. Be careful of the chrome plated parts when it becomes peeled off. Allow only people to sit in the chair. Placing any other heavy objects on the seat may cause deformation and damage, leading to injury. -
Page 7: Precautions For Handling Synthetic Leather
Precautions for Handling Synthetic Leather ●Stains caused by clothing dyes. The synthetic leather of this product may become stained by direct contact with clothes or belts. If it became stained, wipe clean as quickly as possible with a 10% detergent solution diluted using water to prevent permanent staining. ●Take care of deformation or stains due to direct contact. -
Page 8: Name Of Parts
Name of Parts Main body Backrest Armrest Manual switch Seat Armrest switch （Chrome plated part） Leg rest Backrest Backrest frame Fall-prevention bar Chair upper Adjuster cover Adjuster cover (black) (chrome plated) Chair base Power switch Foot switch Base cover Power plug （Auto switch）... -
Page 9: Preparation
Preparation Installation Install the chair as per below correlation diagram. (ａ) (ａ) ①MINON ②MAJOLICA (ｂ) (ｂ) (ｃ) (ｃ) (ａ) (ａ) ③SHAMPOO STATION ④AQUAVIBRO 803N (ｂ) (ｂ) (ｃ) (ｃ) (ａ) (ｃ) (ｂ) Height difference of backrest Name of basin From top of backrest From center of back side adjuster - neck (without neck cushion) -Front end of basin... -
Page 10: 2Adjusting The Adjuster
Adjusting the Adjuster After installation, if the chair may rattle due to floor, adjust the adjuster so to make the chair stable and horizontal to floor. Turn the adjuster cover to the loosen direction (as per the picture at the right). Adjuster cover Tilt up the chair base, turn and adjust the adjuster and make it stable to the... -
Page 11: 4Attaching The Step Adjuster Of The Step Type
Attaching the Step Adjuster of the Step Type (Product Code of the Step Type：SC-S81SL、SC-S81SM、SC-S81SH) Adjuster holder Adjuster Attach the step adjuster as per the above illustration. The parts to use and the attachment distance should be referred to the below. Adjuster holder（77L）... -
Page 12: 5Power
Power Insert the power plug into Power plug an outlet. ●Ensure that this product is the only appliance connected to the outlet. ●Insert the power plug into an outlet all the way to the base. When unplugging, hold the plug at its head and do not pull it at the cord. ●Electric works should be done by a professional. Ground items properly. Failure to follow this instruction may cause electric shock if there is a malfunction or ground leakage. Turn ON/OFF the power switch. Power switch ■ The power switch is located at the left side of the base. The power turns ON if the right side (l mark) is pushed, and turns OFF if the left side ( ○ mark) is pushed. -
Page 13: How To Use
How to Use Guiding Customers Check and ensure that the seat is at its lowest postion. (Refer to page. 15, Return to the initial position) Guide the customer to sit. For small customers, it would be easier to set to appropriate shampooing position, if customers would sit fully back in the seat. - Page 14 Setting to Shampooing Position Continuation from the previous page How to adjust the preset shampooing position The standard preset shampooing position available with auto switch is already set at factory. However, you can DOWN change this position according to your needs. １ Use the manual switch and move the chair to your desired preset shampooing position.
-
Page 15: 3Return To The Initial Position
Return to the Initial Position (Using the auto return function) Pressing up the auto switch will automatically bring the chair back to the initial position. (The backrest raises while the seat lowers. Simultaneously, ※ the leg rest lowers.) ※Leg rest does not move and stays fixed for the step type (SC-S81SL, Auto switch SC-S81SM, SC-S81SH). Auto return function Pressing up the auto switch once will automatically bring the chair back to the initial position. ●Take care of the surroundings before operating the chair. Make sure that no one is near the chair. Getting pinched by the moving chair will lead to injury. ●This chair has a leg rest that moves along with the backrest movement. When moving the backrest, take care of customerʼs legs and surrounding equipment. ●Do not use the auto return function for elderly customers and children. Using this function for elderly customers and children may injure them by giving improper posture or body pressure. Please always use the manual switch to Warning return the chair back to the initial position. ●Take care of customerʼs arms and hands when moving the backrest. Make sure not to pinch them between the backrest and the armrest. Cancellation function To stop the chair movement while the chair is moving in the automatic mode (auto set / auto return), press either the auto or manual switch once. This will immediately stop the chair movement. Pressing the switch again will regain the chair movement. ... -
Page 16: Maintenance
■ This is caused by the grease inside the product cooling down over the ■ Abnormal sound appears at night, and is not a mechanical fault. The sound will disappear after a while. the start of the day. ● To request after-sales services, contact your nearest dealer or Takara Belmont. -
Page 17: Specification
Specification Product Code SC-S81 Rated Voltage AC 220V AC 230V AC 240V Rated Frequency 50/60Hz 50/60Hz 50/60Hz Rated Current 1.7/1.8A 2.0/1.9A 2.1/1.9A Net Weight 90kg Drive Method Electro hydraulic Seat Stroke 215mm Reclining Angle 12°～ 68° Leg rest Angle 28°～ 84° Operating temperature 10 ～... -
Page 18: Standard Period Of Use
(*The level and period of wear, degradation, or damage may differ depending on each usage environment.). Please contact your nearest dealer or Takara Belmont for any damaged parts. External scratches or dirt, degradation, or fading of the following external parts are not covered by warranty. -
Page 19: Memo
Memo... -
Page 20: Procesures For Dainly Inspections
Stop using the product and contact your nearest dealer or Takara Belmont. □Has no air entered into □Check that the chair will not sink when □Customers may not be able to get in/out of the...
