If the unit canno t be adjusted or if values are out of ran g e, proceed to the F lowchart
Entry P oint: Pg. 4A-20.
POKEY SOFTFIRE TEST
Connect the oscilloscope to pin 1 6 of A7 (l v/divisionjl O ms/div.).
•
Insert the controller into port 1.
•
Press key 5 followed by ST ART.
•
Press the top fire button (softfire).
•
A 5v p-p square wave signal should appear.
•
SOFTF IRE TRO UBLESHOOTIN G FLOW CHART, page 4 A- 1 9.
Unplug the controller from port 1 and plug it into port 2.
•
Repeat the fourth and fifth steps for port 2 .
•
CX5200 Field S ervic e Manual
If it does not, proceed to the
3 A- l O
