Outer Case
T he outer case consists of a top and a botto m plastic cover which are held together by
5 phillips head screws.
A t the base of the bottom cover is a cable wrap post for cord storage.
The top cover provides the following (visible from the outside):
an opening in the center for the cue ball.
•
the STA RT, P AUSE and RESET buttons. Their functions are:
•
START - is used to start the game being played.
P AUSE - temporarily stops the game during play.
RESET - per manently stops game play until the Start button is
pressed.
Two conductive rubber keypads; one on each side of the console. The two
•
keypads are identical - one is for left handed players; the other is for right
handed players.
5200 controller.
Two identical sets of fire buttons (for use by right handed or left handed
•
players).
botto m fire buttons on the regular Model 5200 contr oller . The two buttons
c losest to the o utside of the console are the same as the top fire buttons on
the regular Model 5200 contr oller.
The underside of the top cover houses t he keypad PC board.
buttons make contact against this board. The fire buttons are dome type.
The remaining buttons (the START, P AUSE, RESET and the keypad
buttons) are all the conductive rubber type.
Bottom Cover
The bottom cover provides:
an opening at the rear for the game cable
•
the main P C Board
•
two roller shaft assemblies each consisting of:
•
a roller shaft
2 bearings
a slotted encoding wheel
an idler shaft assembly
•
a cue ball
•
CX5200 Field Service Manual
The use is the same as the keypad on the regular M odel
The two buttons closest to the cue ball are the same as the
7 -4
All of the
