Atari CX 5200 Field Service Manual page 166

LOCATION
C 3 9
C4 1 ,42, 1 l 9, 1 44
C43,44
C45
C56-59,69 -72 ,74-
7 7,87-9 0, 1 1 0, 1 1 5
C 1 l 6
C 1 40
C 1 4 5 , 55
R 1
R2
R3
R4-7 , 1 6,27,32 , 34-
37,47,55,56,60, 1 2 4,
1 36
R9
R 1 0 , 1 7-2 1 ,30, 39
44 ,59,66,50 , 1 0 1
1 4 0, 1 4 1
R 1 1 , 1 4,68, 1 3 1
R 1 2 , 6 1 , 69, 1 35
R 1 3
R22,64
R23
R2 4
R25
R26,40
R28, 1 4 2
R29,46
R 3 1 , 4 3 , 65, 125
R33
R4 1
R42
R45
R48, 4 9
R5 1 , 1 37
R52
R53
R54
R57 , 58
R62,63
R67
R70
C X5200 Field Service Manual
DESCRIPTION
UB-
PCB S ASSY (2-PORT)
Cap, Ceramic Axial, 68pf, 50 Y
Cap, Tantalum Axial, 1 0uf
Cap, Polyester Radial, .22uf, 1 00 Y
Cap, Electrolytic Radial, 47uf, 2 5Y
Cap, Ceramic Axial, 47 0pf, 50Y
Cap, Ceramic Axial, .22uf, 50Y
Cap, Ceramic Axial, 3 3pf, 50 Y
Cap, Ceramic Axial, 390pf, 50Y
Res., Car bon F ilm, 4 7 0 K Ohm , 1 /4 W
Res., Carbon F ilm, l OOK Ohm , 1 /4 W
Res., Car bon Film, 1 Meg Ohm , 1 /4 W
Res., Car bon Film, 4.7K Ohm , 1 /4 W
Res., Carbon Film, 9 1 Ohm, 1 /4 W
Res., Carbon Film, 1 K Ohm, 1 /4 W
Res., Carbon F ilm, 220 Ohm , 1 /4 W
Res., Carbon F ilm, 2 .2K Ohm , 1 /4 W
Res., Carbon F ilm, 2 4 0 Ohm, 1 /4 W
Res., Carbon F ilm, 8.2K Ohm , 1 /4 W
Res., Carbon F ilm, 82K Ohm , 1 /4 W
Res., Carbon Film, 3 9K Ohm , 1 /4 W
Res., Carbon F ilm, 2 0 K Ohm, 1 /4 W
Res., Carbon FUm, 1 0K Ohm , 1 /4 W
Res., Carbon F ilm, 3 . 3 K Ohm , 1 /4 W
Res., Carbon F ilm, 1 2K Ohm , 1 /4 W
Res., Carbon F Um, 6.8K Ohm, 1 /4 W
Res., Carbon F ilm, 5 1 0 Ohm , 1 /4 W
Res., Carbon F ilm, 1 8K Ohm , 1 /4 W
Res., Car bon F ilm, 9. 1 K Ohm , 1 /4 W
Res., Carbon F ilm, 1 5K Ohm , 1 /4 W
Res., Carbon Film, 4 7 K Ohm , 1 /4 W
Res., Carbon F ilm, 1 0 Ohm , 1 /4 W
Res., Carbon F ilm, 5. 1 K Ohm, 1 /4 W
Res., Carbon F ilm, 5 6 Ohm , 1 /4 W
Res., Carbon F ilm, 560 Ohm , 1 /4 W
Res., Carbon Met al F il m , 3 3 0 Ohm, 1 W
Res., Carbon F il m , 22K Ohm, 1 /4 W
Res., Carbon F ilm, 1 50 Ohm , 1 /4 W
Res., Carbon F il m , 1 . 5K Ohm , 1 /4 W
8-9
PART NUMBER
CA021 375
C0 1 4 1 79-1 2
C0 1 75 1 6
C0 1 0394
C020 1 2 1
C O 1 4 1 79-1 6
C0 1 4 1 8 1 -0 5
C0 1 4 1 79-04
C0 1 4 1 79-24
1 4-547 4
1 4-5 1 0 4
1 4-5 1 0 5
1 4 -5472
1 4-59 1 0
1 4-5 1 02
1 4-522 1
1 4-5222
1 4-524 1
1 4-5822
1 4-5823
1 4-5 393
1 4-520 3
1 4-5 1 0 3
1 4-5332
1 4-5 1 23
1 4-5682
1 4-55 1 1
1 4-5 1 83
1 4-59 1 2
1 4-5 1 53
1 4-547 3
1 4-5 1 00
1 4-55 1 2
1 4-5560
1 4-556 1
C0 1 8 1 88-02
1 4 -5223
1 4-5 1 5 1
1 4-5 1 52
Changed by
ECN /10036
6 /2 1 /83
