1 .
To re place joystick:
Place boot in position on 'outside of top contr oller case.
Position actuator plates and slide block in underside of to p controller
case.
From underside, place pivot shaft through holes in slide block and boot.
From top, push j oystick onto pivot shaft.
Replace the fire buttons and place the key pad on the support plate (refer to
2.
F igure 6-0.
P osition the pot arms as shown in Figure 6-8.
3.
CX5200 Field Service Manual
F igure 6-7 . Controller Knob Removal
Figure 6-8.
Pot Arm P ositions
6-1 1
Assembly
for
Changed by
ECN /10036
6/21 /83
