Parts
™
LineLazer
Standard Series and High Production (HP) Auto Series
For the application of line striping materials.
For professional use only.
For outdoor use only.
Not for use in explosive atmospheres or hazardous locations.
Maximum Operating Pressure: 3300 psi (22.8 MPa, 228 bar)
Important Safety Instructions
Read all warnings and instructions in this manual and in related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Related Manuals:
3A3388
Operation
311254
Gun
309277
Pump
3A3428
Auto-Layout Applications Methods
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
V 3900, 5900 Airless Line Stripers
ti27499a
3A3389D
EN
Advertisement
Table of Contents
Related Manuals for Graco LineLazer V 3900 17H449
Summary of Contents for Graco LineLazer V 3900 17H449
- Page 1 Be familiar with the controls and the proper usage of the equipment. Save these instructions. Related Manuals: 3A3388 Operation 311254 309277 Pump 3A3428 Auto-Layout Applications Methods ti27499a Use only genuine Graco replacement parts. The use of non-Graco replacement parts may void warranty.
-
Page 2: Table Of Contents
Graco Standard Warranty ....26 Graco Information ......26... -
Page 3: Models
Models Models LineLazer V 3900 Model: Standard Standard HP Auto HP Auto HP Auto 1 Manual Gun 2 Manual Guns 1 Auto Gun 1 Auto Gun 2 Auto Guns 1 Manual Gun 17H449 17H450 17K577 17H451 with laser 17K638 ... -
Page 4: Tip Selection
Tip Selection Tip Selection (cm) (cm) (cm) (cm) LL5213* 2 (5) LL5215* 2 (5) LL5217 4 (10) LL5219 4 (10) LL5315* 4 (10) LL5317 4 (10) LL5319 4 (10) LL5321 4 (10) LL5323 4 (10) ... -
Page 5: Linelazer V 3900, 5900 Parts
LineLazer V 3900, 5900 Parts LineLazer V 3900, 5900 Parts Page 14 Page 12 Page 16 Page 8 & 10 Page 6 Page 12 Page 14 ti28061a 3A3389... -
Page 6: Parts Drawing - Linelazer V 3900, 5900
Parts Drawing - LineLazer V 3900, 5900 Parts Drawing - LineLazer V 3900, 5900 Torque to 45-55 ft-lbs (61.0-74.5 N·m) Torque to 17-23 ft-lbs (23.0-31.1 N·m) Rear tire pressure 58-62 psi ref 125g (3.9-4.2 bar) Torque to 190-210 in-lbs (21.4-23.7 N·m) Torque to 130-150 in-lbs (14.6-16.9 N·m) Torque to 23-27 ft-lbs... -
Page 7: Parts List
Parts List Parts List Part Description Part Description 17J136 SCREW, hex, flange head 287623 FRAME, linestriper (painted) 196176 ADAPTER, nipple 101566 NUT, lock 114659 GRIP 193405 AXLE 237686 GROUND WIRE 198891 BRACKET 107257 SCREW, thread forming, hex hd 198930 ROD, brake (includes 12) 194310 LEVEL, actuator 198931 BEARING 245225 HOSE, 3/8”... -
Page 8: Parts Drawing - Linelazer V 3900, 5900
Parts Drawing - LineLazer V 3900, 5900 Parts Drawing - LineLazer V 3900, 5900 Torque to 130-150 in-lbs (14.6-16.9 N·m) Torque to 190-210 in-lbs (21.4-23.7 N·m) Torque to 17-23 ft-lbs (23.0-31.1 N·m) Torque to 170-190 in-lbs (19.2-21.4 N·m) Torque to 115-135 in-lbs (12.9-15.2 N·m) Torque to 30-35 in-lbs (3.3-3.9 N·m) -
Page 9: Parts List
Parts List Parts List Part Description Part Description 287719 ROD, connecting, 3900 (includes 119695 DAMPENER, engine mount 93, 94) 15F583 PLATE, engine mount 287720 ROD, connecting, 5900 (includes 108851 WASHER, plain 113743 SCREW, cap, hex hd 93, 94) 101566 NUT, lock 15F855 PIN, pump, 3900 108879 ENGINE, gasoline, 4.0 hp, 3900 15F856 PIN, pump, 5900... -
Page 10: Parts Drawing - Drive And Pinion Housing Assemblies
Parts Drawing - Drive and Pinion Housing Assemblies Parts Drawing - Drive and Pinion Housing Assemblies ref 81 ref 75 ref 80 ref 72 ref 82 ref 84 Pinion housing assembly (79) includes clutch field and connector. ref 83 ref 85 ref 83 ti28145a 3A3389... -
Page 11: Parts List
Parts List Parts List Ref No. 86 and 79 Ref No. 79: Pinion Housing Assembly 287463 for Ref No. 86: Drive Housing Assembly 287467 for LineLazer V 3900; Pinion Housing Assembly 287465 for LineLazer V 3900; Drive Housing Assembly 287469 for LineLazer V 5900 LineLazer V 5900 Part... -
Page 12: Parts Drawing - Linelazer V 3900, 5900
Parts Drawing - LineLazer V 3900, 5900 Parts Drawing - LineLazer V 3900, 5900 Swivel Wheel Assembly & Filter Torque to 35-45 ft-lbs (47.4-61.0 N·m) Torque to 190-210 in-lbs (21.4-23.7 N·m) Torque to 365-385 in-lbs (41.2-43.4 N·m) Torque to 25-30 in-lbs (2.8-3.3 N·m) Torque to 23-27 ft-lbs (31.1-36.6 N·m) -
Page 13: Parts List
Parts List Parts List Swivel Wheel Assembly Filter Part Description Part Description 101566 NUT, lock 17K166 MANIFOLD 112960 SCREW, cap, flng hd 196179 FITTING, elbow, street 111040 NUT, lock, insert, nylon, 5/16 287285 CAP, filter (includes 54, 56) 18*‡ 112405 NUT, lock 15C766 TUBE, diffusion ‡... -
Page 14: Parts Drawing - Linelazer V 3900, 5900
Parts Drawing - LineLazer V 3900, 5900 Parts Drawing - LineLazer V 3900, 5900 119m 119a 119L 119b 119c 119g 119h 119d 119i 119f 119e 119k 119j 116a 116c 116b ti28050a Torque to 17-23 ft-lbs (23.0-31.1 N·m) Torque to 18-22 in-lbs (2.0-2.4 N·m) 130e 130a... -
Page 15: Parts List
Parts List Parts List Gun Holder and Arm Gun Trigger Part Description Part Description 101566 NUT, lock 25A488 CABLE, gun, manual (includes 114982 SCREW, cap, flng hd 126, 151) 17H528 BRACKET, gun arm 245798 HOSE, coupled 1/4” x 7’ 17J407 ARM, extension, bar 15F624 NUT, cable, gun (knurled) 17J424 BAR, height adjustment, assy 25A636 BRACKET, trigger w switch... -
Page 16: Parts Drawing - Linelazer V 3900, 5900
Parts Drawing - LineLazer V 3900, 5900 Parts Drawing - LineLazer V 3900, 5900 Torque to 18-22 in-lbs NOTICE (2.0-2.4 N·m) Do not allow the solenoid wires 0.75" to make a sharp bend as shown. Torque to 130-150 in-lbs Doing so may lead to wire (14.6-16.9 N·m) breakage. -
Page 17: Parts List
Parts List Parts List Part Description Part Description 114687 CLIP, retainer 24Y665 FRAME, handle upright, painted 17H701 GROMMET, oval 17J123 PLATE, cover 115483 NUT, lock 17J135 COVER, control, painted (Series A) 17K378 LABEL 17V517 COVER, control, painted (Series B) 17K379 LABEL 128978 SCREW, mach, slot hex wash hd 17K377 COVER, battery, painted 24Y643 CONTROL, throttle (includes 401,... -
Page 18: Distance Sensor Replacement
Distance Sensor Replacement Distance Sensor Replacement 1. Remove wheel (17) from LineLazer. 3. Install new distance (23) with wire clamp (24) and screw (25). 2. Remove screw (25), wire clamp (24) and distance sensor (23). 4. Install wheel (17) on LineLazer. 3A3389... -
Page 19: Wiring Diagram (Standard Series)
Wiring Diagram (Standard Series) Wiring Diagram (Standard Series) 3A3389... -
Page 20: Wiring Diagram (Hp Auto Series)
Wiring Diagram (HP Auto Series) Wiring Diagram (HP Auto Series) 3A3389... -
Page 21: Technical Data
Technical Data Technical Data LineLazer V 3900 Standard Series (Models 17H449, 17H450) U.S. Metric Dimensions Height Unpackaged - 44.5 in. Unpackaged - 113.03 cm Packaged - 52.5 in. Packaged - 133.35 cm Width Unpackaged - 34.25 in. Unpackaged - 86.99 cm Packaged - 37.0 in. - Page 22 Technical Data LineLazer V 5900 Standard Series (Models 17H454, 17H455) U.S. Metric Dimensions Height (with handle bar down) Unpackaged - 44.5 in. Unpackaged - 113.03 cm Packaged - 52.5 in. Packaged - 133.35 cm Width Unpackaged - 34.25 in. Unpackaged - 86.99 cm Packaged - 37.0 in.
- Page 23 Technical Data LineLazer V 3900 HP Auto Series (Models 17K577, 17H451, 17K638, 17H452, 17K579, 17H453) U.S. Metric Dimensions Height (with handle bar down) Unpackaged - 44.5 in. Unpackaged - 113.03 cm Packaged - 52.5 in. Packaged - 133.35 cm Width Unpackaged - 34.25 in.
- Page 24 Technical Data LineLazer V 5900 HP Auto Series (Models 17K580, 17H456, 17K636, 17H457, 17K581, 17H458) U.S. Metric Dimensions Height (with handle bar down) Unpackaged - 44.5 in. Unpackaged - 113.03 cm Packaged - 52.5 in. Packaged - 133.35 cm Width Unpackaged - 34.25 in.
-
Page 25: Notes
Notes Notes 3A3389... -
Page 26: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
