ICP DAS USA PCI-1202 Quick Start Manual

I/o card
Hide thumbs Also See for PCI-1202:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
......................................................
1
What's on your package?
One PCI-1202/1602/180x series card
One companion PCI CD (V3.6 or later)
One Quick Start Guide(This document)
......................................................
2
Installing Windows Driver
Follow those steps:
1. Setup the Windows driver.
You can get the driver from:
PCI-1202 :
CD:\NAPDOS\PCI\PCI-1202\DLL_OCX\
http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-1202/dll_ocx/
PCI-1202/1602/180x
Language
Version
Update
- 1 -
English
V1.0
Oct.2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI-1202 and is the answer not in the manual?

Questions and answers

Related Manuals for ICP DAS USA PCI-1202

Summary of Contents for ICP DAS USA PCI-1202

  • Page 1 Language Version V1.0 Update Oct.2008 ……………………………………………… What’s on your package? One PCI-1202/1602/180x series card One companion PCI CD (V3.6 or later) One Quick Start Guide(This document) ……………………………………………… Installing Windows Driver Follow those steps: 1. Setup the Windows driver. You can get the driver from:...
  • Page 2 PCI-1602: CD:\NAPDOS\PCI\PCI-1602\DLL_OCX\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-1602/dll_ocx/ PCI-180x: CD:\NAPDOS\PCI\PCI-180x\DLL_OCX\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-180x/dll_ocx/ 2. Click button to start installation. 3. Click button to install driver into the default folder. 4. Click button to continue installation. 5. Select “NO, I will restart my computer later” and then click button.

  • Page 3: Jp1 : A/D Input Type Selection

    ……………………………………………… Jumper Setting JP1 : A/D Input Type Selection Differential Single-Ended Inputs Inputs (default) J1 : D/A Reference Voltage Selection ± 5 Voltage ± 10 Voltage output output (default) D/I Port Setting (PCI-1202HU/LU only) Pull Low Pull High - 3 -...

  • Page 4: Pin Assignments

    ……………………………………………… Pin Assignments CON1: Digital Output connector. Name Name Digital output 0 Digital output 1 Digital output 2 Digital output 3 Digital output 4 Digital output 5 Digital output 6 Digital output 7 Digital output 8 Digital output 9 Digital output 10 Digital output 11 Digital output 12 Digital output 13...
  • Page 5 CN3: Single-Ended/Differential Input. (For PCI-1202/1602/1802H/L/HU/LU) (For PCI-1800H/L) Pin Name Pin Name Pin Name Pin Name Analog input 0/0+ Analog input 16/0- Analog input 0/0+ 20 Analog input 8/0- Analog input 1/1+ Analog input 17/1- Analog input 1/1+ 21 Analog input 9/1-...
  • Page 6 ……………………………………………… Self-Test Use CA-2002(Optional) to connect the CN1 with CN2. Run the PCI-1202/1602/180x sample program. Get the file from: PCI-1202: CD:\NAPDOS\PCI\PCI-1202/DLL_OCX/Demo\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-1202/dll_ocx/demo/ PCI-1602: CD:\NAPDOS\PCI\PCI-1602/DLL_OCX/Demo\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-1602/dll_ocx/demo/ PCI-180x: CD:\NAPDOS\PCI\PCI-180x/DLL_OCX/Demo\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-180x/dll_ocx/demo/ - 6 -...

  • Page 7: Dio Function

    Check number of the PCI-1202/1602/180x and test DIO function. 3. Click this button to do DIO test. 1. The one PCI-1202/1602/ 180x had successfully installed to PC. 2. Select the board number for the PCI-1202/1602/180x. It starts from 0. Get DIO function test result.

  • Page 8: Additional Information

    ……………………………………………… Additional Information PCI-1202/1602/180x Series Card Product page: http://www.icpdas.com/products/DAQ/pc_based/pci_1202.htm http://www.icpdas.com/products/DAQ/pc_based/pci_1602.htm http://www.icpdas.com/products/DAQ/pc_based/pci_1800.htm CA-2002(Optional) page: http://www.icpdas.com/products/Accessories/cable/cable_selection.htm Documents: CD:\NAPDOS\PCI\PCI-1202\Manual (PCI-1602, PCI-180x) http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-1202/manual/ (PCI-1602, PCI-180x) Software: CD:\NAPDOS\PCI\PCI-1202 (PCI-1602, PCI-180x) http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-1202/ (PCI-1602, PCI-180x) The ICP DAS Web Site http://www.icpdas.com Technical support Supplies and ordering information...
