Cleaning The Condenser Coil - Delfield F5MC36DV Installation, Operation And Maintenance Manual

Section 4

Cleaning The Condenser Coil

In order to maintain proper refrigeration performance, the
condenser fins must be cleaned of dust, dirt and grease
regularly. It is recommended that this be done monthly. If
conditions are such that the condenser is totally blocked
in a month, the frequency of cleaning should be increased.
Clean the condenser with a vacuum cleaner or stiff brush. If
extremely dirty, a commercially available condenser cleaner
may be required.
Failure to maintain a clean condenser coil can initially cause
high temperatures and excessive run times. Continuous
operation with a dirty or clogged condenser coil can
result in compressor failure. Neglecting the condenser coil
cleaning procedures will void any warranties associated
with the compressor and cost to replace the compressor.
Cleaning The Condensate Evaporator
REMOTE MODELS ONLY
The stainless steel condensate evaporator pan should be
cleaned every six months. Use a vacuum cleaner or damp
cloth to remove dust that may have accumulated. This will
prevent corrosion of the stainless steel.
Door Maintenance
DOORS WITH HINGES
Over time and with heavy-use doors, the hinges may
become loose. If this happens, tighten the screws that
mount the hinge brackets to the frame of the unit. Loose
or sagging doors can cause the hinges to pull out of the
frame, which may damage both the doors and the hinges.
In some cases this may require qualified service agents or
maintenance personnel to perform repairs.
Part Number: 9291460 11/17
SLIDING DOORS
Standard With Door Lock
Clean the tracks weekly with a mild soap and water solution
to keep the tracks free of foreign matter. The glass may be
cleaned with one of the many commercial glass cleaners
available.
Sliding Door Removal
If it becomes necessary to replace a sliding door as sem bly
or a glass panel, have your unit's model and serial numbers
available when you call KitchenCare (844) 724-2273.
Indicate that your unit has the sliding door assembly when
you call.
1. Open the door almost completely.
2. Firmly grasp both sides of the door.
3. Lift the door up and move it until it enters a notch and
can be lifted higher.
4. Tilt the bottom out without removing the top.
5. Use the top to gently return the spring to the closed
position.
6. Remove the door from the top track.
Sliding Door Reinstall
1. Use the top inside corner of the door to move the
spring to the open position.
2. Put the top into the track and find the notch where the
door can be lifted higher.
3. Set bottom of the door into the track.
Maintenance
23
