2-8. Dimensions of Snow Ducting

Reference diagram for snow-proof ducting (field supply)
CHX03652/06052
1 Unit top, snow-proof vent
2 Unit left side
3 Unit right side
4 Unit reverse side
3
Fastened by screws at
3 locations (also on reverse side)
Fastened by screw at
1 location (also on reverse side)

2-9. Dimensions of Outdoor Unit with Snow-Proof Ducting (field supply)

CHX03652/06052
Fastened by screws at 13 locations
25-13/32
17-15/32
3-3/4
1-5/8
15-9/32
30-3/32 7-1/16
Wind direction
Wind direction
Wind direction Wind direction
37
24-7/8
30-3/32
19-11/16
5/8
28-3/4
30-5/8
Unit: in.
11-29/32
Wind direction
22
4
Unit: in.
1
11-7/8
3-31/32
1-3/16
Wind direction
2
