85464369235000 ©SANYO 2009

INSTALLATION INSTRUCTIONS

– W-2WAY System Air Conditioner –

for Refrigerant R410A

This air conditioner uses the new refrigerant R410A.

External diameter of service port R410A: 5/16"

NOTE

XHX1252

XMHX1252

THX1252

FHX0962

FHX1262

CHDX07263

CHDXR07263

XHX1852

XMHX1852

THX1852

KHX1862 KHX1962 KHX2452

FHX1562

FHX1862

CHDX09663

CHDXR09663

RCS-TM80BG

RCS-BH80AAB.WL

RCS-SH80AAB.WL

RCS-XM18AAB.WL

RCS-TRP80AAB.WL

RCS-SH1AAB

RCS-KR1EG

SHA-KC64UG

SHA-TM64AGB

SHA-KT256EA

SHA-KA128AAB

ART-K45AGB

SHA-LN16UAB

SANYO North America Corporation

Commercial Solutions Division

2055 Sanyo Ave., San Diego

CA 92154, U.S.A.

XHX2452 XHX3652

UHX2462 UHX3662 UHX4862 UHX5462

DHX3652 DHX4852

THX2452

FHX2462

FMHX2462

In Canada

SANYO Canada Inc.

201 Creditview Road, Woodbridge

Ontario, L4L 9T1, Canada

Table of Contents

Summary of Contents for Sanyo XM18AAB

Page 1 Communication Adaptor SHA-KA128AAB Remote Sensor ART-K45AGB LonWorks Interface SHA-LN16UAB SANYO North America Corporation In Canada Commercial Solutions Division SANYO Canada Inc. 2055 Sanyo Ave., San Diego 201 Creditview Road, Woodbridge CA 92154, U.S.A. Ontario, L4L 9T1, Canada 85464369235000 ©SANYO 2009...
Page 2: Important
IMPORTANT! Please Read Before Starting When Installing… This air conditioning system meets strict safety and operat- ing standards. As the installer or service person, it is an …In a Room important part of your job to install or service the system so it Properly insulate any tubing run inside a room to prevent operates safely and efficiently.
Page 3: Check Of Density Limit
Check of Density Limit The room in which the air conditioner is to be installed requires a design that in the event of refrig- erant gas leaking out, its density will not exceed a set limit. The refrigerant (R410A), which is used in the air condition- er, is safe, without the toxicity or combustibility of ammonia, and is not restricted by laws imposed to protect the ozone layer.
Page 4: Precautions For Installation Using New Refrigerant
Precautions for Installation Using New Refrigerant 1. Care regarding tubing 1-1. Process tubing ● Material: Use C1220 phosphorous deoxidized copper specified in JIS H3300 “Copper and Copper Alloy Seamless Pipes and Tubes.” For tubes of ø7/8" (ø22.22 mm) or larger, use C1220 T-1/2H material or H material, and do not bend the tubes. ●...
Page 5: New Refrigerant R410A Cannot Be Used For Earlier Models
3-2. Use R410A exclusive cylinder only. Valve Single-outlet valve (with siphon tube) Liquid refrigerant should be recharged with the cylinder standing on end as shown. Liquid New refrigerant R410A cannot be used for earlier models 1. Compressor specifications are different. If recharging a R22 or R407C compressor with R410A, durability will significantly decrease since some of the materials used for compressor parts are...
Page 6: Table Of Contents
CONTENTS Page Page IMPORTANT! ......2 5. HOW TO PROCESS TUBING ... . 28 Please Read Before Starting 5-1.
Page 7: General
1. GENERAL This booklet briefly outlines where and how to install the air conditioning system. Please read over the entire set of instructions for the outdoor unit and make sure all accessory parts listed are with the system before beginning. 1-1.
Page 8: Tubing Length
1-5. Tubing Length Select the installation location so that the length and size of refrigerant tubing are within the allowable range shown in the figure below. Main tubing length LM = LA + LB … 262 ft Main distribution tubes LC – LH are selected according to the capacity after the distribution joint. The outdoor connection main tubing (LO portion) is determined by the total capacity of the ...
Page 9: Tubing Size
1-6. Tubing Size Table 1-3 Main Tubing Size (LA) Unit: in. (mm) BTU/h 72,000 96,000 144,000 192,000 216,000 240,000 264,000 288,000 (kW) (21.1) (28.1) (42.2) (56.2) (63.3) (70.3) (77.3) (84.3) Total system horsepower Combined outdoor units o7/8" o1-1/8" o1-3/8" Gas tubing (o22.22) (o28.58) (o34.92)
Page 10: Straight Equivalent Length Of Joints
1-7. Straight Equivalent Length of Joints Design the tubing system by referring to the following table for the straight equivalent length of joints. Unit: ft. Table 1-8 Straight Equivalent Length of Joints 1/2" 5/8" 3/4" 7/8" 1" 1-1/8" 1-3/8" 1-5/8" Gas tubing size (in.
Page 11: Check Of Limit Density
Always check the gas density WARNING limit for the room in which the unit is installed. 1-10. Check of Limit Density When installing an air conditioner in a room, it is necessary to ensure that even if the refrigerant gas accidentally leaks out, its density does not exceed the limit level for that room.
Page 12: Optional Distribution Joint Kits
1-12. Optional Distribution Joint Kits See the installation instructions packaged with the distribution joint kit for the installation procedure. Table 1-12 Model name Cooling capacity after distribution Remarks 1. APR-CHP680BA 232,000 BTU/h (68.0 kW) or less For outdoor unit 2. APR-CHP1350BA 460,700 BTU/h (135.0 kW) or less For outdoor unit 3.
Page 13 3. APR-P160BA Use: For indoor unit (Capacity after distribution joint is 76,400 BTU/h (22.4 kW) or less.) Example: Gas tubing Liquid tubing 4-21/64 4-21/64 3-13/16 3-13/16 Distr ib utio n Distr ib utio n Insulation Insulation Joint Joint Unit: in. Table 1-15 Size of connection point on each part (Shown are inside diameters of tubing) Size Part A...
Page 14: Example Of Tubing Size Selection And Refrigerant Charge Amount
1-13. Example of Tubing Size Selection and Refrigerant Charge Amount Additional refrigerant charging Based on the values in Tables 1-3, 4, 5, 7, 10-1 and 10-2, use the liquid tubing size and length, and calculate the amount of addi- tional refrigerant charge using the formula below. Required additional = Necessary Amount of Additional Refrigerant Charge Per Outdoor Unit refrigerant charge (oz)
Page 15 ● Obtain liquid tubing size from Tables 1-3, 4, 5, 7 and 10-1. Main tubing LA = ø5/8 (ft.) (Total capacity of indoor unit is 179,400 BTU/h) The longest tubing length in this example LB = ø1/2 (ft.) (Total capacity of indoor unit is 131,600 BTU/h) (LA = 131 ft.) LC = ø3/8 (ft.) (Total capacity of indoor unit is 83,800 BTU/h) Distribution joint tubing...
Page 16: Selecting The Installation Site
2. SELECTING THE INSTALLATION SITE Exhaust fan 2-1. Outdoor Unit Hot air AVOID: Heat source Out- ● heat sources, exhaust fans, etc. door ● damp, humid or uneven locations unit ● indoors (no-ventilation location) Fig. 2-1 ● choose a place as cool as possible. ●...
Page 17: Shield For Horizontal Exhaust Discharge
2-2. Shield for Horizontal Exhaust Discharge It is necessary to install an air-discharge chamber (field supply) to direct exhaust from the fan horizontally if it is diffi- cult to provide a minimum space of 7 ft. between the air-dis- charge outlet and a nearby obstacle. (Fig. 2-4) In regions with heavy snowfall, the outdoor unit should be CAUTION...
Page 18: Dimensions Of Wind Ducting
2-5. Dimensions of Wind Ducting Reference diagram for air-discharge chamber (field supply) unit: in. Ceiling panel Ceiling panel Air direction: Front direction Air direction: Right direction 33-3/16 (Ceiling panel dimensions) (Ceiling panel dimensions) (Ceiling panel dimensions) 35-1/4 (Maximum bracket dimensions) Front view Right side view Front view...
Page 19: Dimensions Of Snow Ducting
2-6. Dimensions of Snow Ducting Reference diagram for snow-proof ducting (field supply) 31-1/2 Air direction: Air direction: Front direction Right direction Ceiling panel Ceiling panel 31-1/2 31-1/2 (Air intake duct) unit: in. 33-3/16 (Air outlet duct) 9-1/2 9-1/2 9-1/2 9-1/2 9-1/2 9-1/2 (Ceiling panel dimensions)
Page 20: How To Install The Outdoor Unit
3. HOW TO INSTALL THE OUTDOOR UNIT 3-1. Transporting When transporting the unit, have it delivered as close to the installation site as possible without unpacking. Use a hook for suspending the unit. (Fig. 3-1) CAUTION ● When hoisting the outdoor unit, pass ropes or straps under the bottom plate as shown in the figure at right.
Page 21: Routing The Tubing
3-3. Routing the Tubing ● The tubing can be routed out either from the front or from the bottom. (Fig. 3-6) ● The connecting valve is contained inside the unit. Therefore, remove the front panel. (Fig. 3-6) (1) If the tubing is routed out from the front, use cutting pliers or a similar tool to cut out the tubing outlet slit (part indicated ) from the tubing cover.
Page 22: Prepare The Tubing
3-4. Prepare the Tubing ● Material: Use C1220 phosphorous deoxidized copper as described in JIS H3300, “Copper and Copper Alloy Seamless Pipes and Tubes.” (For tubes that are ø7/8" ø22.22 mm) or larger, use 1/2H material or H material. For all others use O material.) ●...
Page 23 Refrigerant tube port ● Use caulking, putty, or a similar material to fill any gaps at the Bottom plate refrigerant tube port ( ) in order to prevent rainwater, dust or Tubing cover foreign substances from entering the unit. * Perform this work even if the tubing is routed out in a downward direction.
Page 24: Electrical Wiring
4. ELECTRICAL WIRING 4-1. General Precautions on Wiring (7) Regulations on wire diameters differ from locality to (1) Before wiring, confirm the rated voltage of the unit as locality. For field wiring rules, please refer to your shown on its nameplate, then carry out the wiring LOCAL ELECTRICAL CODES before beginning.
Page 25: Wiring System Diagram
4-3. Wiring System Diagram Indoor unit (No. 1) Power supply Outdoor unit INV unit 208 / 230V, 1ø, ~60Hz Power supply Ground 208 / 230V, 3ø, ~60Hz Remote controller Ground Indoor unit (No. 2) Inter-outdoor unit control wiring Power supply 208 / 230V, 1ø, ~60Hz Outdoor unit Ground...
Page 26 CAUTION (1) When linking outdoor units in a network (S-net link system), disconnect the terminal extended from the short plug (CN003, 2P Black, location: right bottom on the outdoor main control PCB) from all outdoor units except any one of the outdoor units. (When shipping: In shorted condition.) Otherwise the communication of S-net link system is not performed.
Page 27 Loose wiring may cause the terminal to overheat or result WARNING in unit malfunction. A fire hazard may also exist. Therefore, ensure that all wiring is tightly connected. When connecting each power wire to the terminal, follow the instructions on “How to connect wiring to the terminal” and fasten the wire securely with the fixing screw of the terminal plate.
Page 28: How To Process Tubing
5. HOW TO PROCESS TUBING Deburring The liquid tubing side is connected by a flare nut, and the After Before gas tubing side is connected by brazing. 5-1. Connecting the Refrigerant Tubing Use of the Flaring Method Many of conventional split system air conditioners employ the flaring method to connect refrigerant tubes which run between indoor and outdoor units.
Page 29: Connecting Tubing Between Indoor And Outdoor Units
Caution Before Connecting Tubes Tightly (1) Apply a sealing cap or water-proof tape to prevent dust or water from entering the tubes before they are used. Apply refrigerant (2) Be sure to apply refrigerant lubricant to the matching lubricant here and here surfaces of the flare and union before connecting them together.
Page 30: Insulating The Refrigerant Tubing
Two tubes arranged together 5-3. Insulating the Refrigerant Tubing Tubing Insulation Liquid tubing Gas tubing ● Thermal insulation must be applied to all unit tubing, including the distribution joint (purchased separately). (Fig. 5-7) Insulation * For gas tubing, the insulation material must be heat resistant to 248°F or above.
Page 31: Taping The Tubes
5-4. Taping the Tubes (1) At this time, the refrigerant tubes (and electrical wiring if local codes permit) should be taped together with armoring tape in 1 bundle. To prevent the condensa- tion from overflowing the drain pan, keep the drain hose separate from the refrigerant tubing.
Page 32: Air Purging
Manifold gauge 6. AIR PURGING Air and moisture in the refrigerant system may have undesirable effects as indicated below. ● pressure in the system rises ● operating current rises ● cooling (or heating) efficiency drops ● moisture in the refrigerant circuit may freeze and block capillary tubing Fig.
Page 33 (4) Do a leak test of all joints of the tubing (both indoor and Manifold valve outdoor) and both gas and liquid service valves. Bub- bles indicate a leak. Wipe off the soap with a clean cloth after a leak test. Pressure gauge (5) After the system is found to be free of leaks, relieve the...
Page 34 Manifold valve NOTE Pressure gauge The required time in the above table is calculated based on the assumption that the ideal (or target) vacuum condition is less than –14.7 psig (–755 mmHg, 5 Torr). Valve (2) When the desired vacuum is reached, close the “Lo” knob of the manifold valve and turn off the vacuum pump.
Page 35: Test Run
7. TEST RUN 7-1. Preparing for Test Run ● Before attempting to start the air conditioner, check the following. (1) All loose matter is removed from the cabinet especially steel filings, bits of wire, and clips. (Power must be turned ON at least 5 hours before (2) The control wiring is correctly connected and all attempting test run)
Page 36: Test Run Procedure
Items to Check Before the Test Run 7-2. Test Run Procedure 1. Turn the remote power switch on at least 5 hours before Recheck the items to check before the test run. the test, in order to energize the crankcase heater. 2.
Page 37: Main Outdoor Unit Pcb Setting
7-3. Main Outdoor Unit PCB Setting CN003 CN101 CN100 S007 S006 S005 S004 S003 S002 Fig. 7-4...
Page 38 ● Examples of the No. of indoor units settings (S005, S004) Indoor unit setting (S005) Indoor unit setting (S004) No. of indoor units (3P DIP switch, blue) (Rotary switch, red) 10 20 30 1 unit (factory setting) All OFF Set to 1 11 units 1 ON Set to 1...
Page 39: Auto Address Setting
7-4. Auto Address Setting Basic wiring diagram: Example (1) • If link wiring is not used (The inter-unit control wires are not connected to multiple refrigerant systems.) Indoor unit addresses can be set without operating the compressors. No. 1 (main outdoor unit) settings No.
Page 40 Basic wiring diagram: Example (2) • If link wiring is used * When multiple outdoor main units exist, remove the socket that is used to short-circuit the terminal plug (CN003) from all No. 1 Refrigerant circuit outdoor main unit PCBs except for one unit. No.
Page 41 Case 2 Automatic Address Setting (no compressor operation) ● Indoor and outdoor unit power can be turned ON for each system separately. Indoor unit addresses can be set without operating the compressors. Automatic Address Setting from Outdoor Unit 1. On the No. 1 (main) unit control PCB, set the unit No. switch (S007) to (unit No.
Page 42 Case 3A Automatic Address Setting in Heating Mode ● Indoor and outdoor unit power cannot be turned ON for each system separately. In the following, automatic setting of indoor unit addresses is not possible if the compressors are not operating. Therefore perform this process only after completing all refrigerant tubing work.
Page 43 Case 3B Automatic Address Setting in Cooling Mode ● Indoor and outdoor unit power cannot be turned ON for each system separately. In the following, automatic setting of indoor unit addresses is not possible if the compressors are not operating. Therefore perform this process only after completing all refrigerant tubing work.
Page 44 Display during automatic address setting ● On outdoor main unit PCB * Do not short-circuit the automatic address setting pin (CN100) again while automatic address set- ting is in progress. Doing so will cancel the setting operation and will cause LEDs 1 and 2 to turn OFF.
Page 45: Remote Controller Test Run Settings
Request concerning recording the indoor/outdoor unit combination Nos. After automatic address setting has been completed, be sure to record them for future reference. List the outdoor main unit system address and the addresses of the indoor units in that system in an easily visible location (next to the nameplate), using a permanent marking pen or similar means that cannot be abraded easily.
Page 46: Caution For Pump Down
7-6. Caution for Pump Down Pump down means refrigerant gas in the system is returned to the outdoor unit. Pump down is used when the unit is to be moved, or before servicing the refrigerant circuit. (Refer to the Service Manual) ●...
Page 47: Meaning Of Alarm Messages
7-7. Meaning of Alarm Messages Table of Self-Diagnostics Functions and Description of Alarm Displays Alarm messages are indicated by the blinking of LED 1 and 2 (D72, D75) on the outdoor unit PCB. They are also displayed on the wired remote controller. ●...
Page 48 Alarm Possible cause of malfunction message Protective device in indoor unit Activation of Thermal protector in indoor unit fan motor is activated. <<P01>> is activated. protective Improper wiring connections of ceiling panel. <<P09>> device Float switch is activated. <<P10>> Operation of protective function of fan inverter. sensor (detects low oxygen level) activated Incorrect discharge temperature.
Page 49 Alarm messages displayed on system controller Indoor or main outdoor unit is not operating correctly. Serial Error in transmitting serial communication signal Mis-wiring of control wiring between indoor unit, main outdoor unit communication and system controller. errors Mis-setting Indoor or main outdoor unit is not operating correctly. Error in receiving serial communication signal Mis-wiring of control wiring between indoor unit, main outdoor unit...
