Ruffneck CX1 ProVector Series Installation, Operation & Maintenance Instructions Manual

Electric convection air heaters for hazardous locations
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

WARNING!
Read all important information notices on page 3. Please adhere to instruction published in this manual.
Failure to do so may be dangerous and may void certain provisions of your warranty.
Electric Convection Air Heaters for Hazardous Locations
CX1 ProVector ® Series
Installation, Operation, & Maintenance Instructions
Model Coding
CX1
-
120
Model
Heater Voltage
Series
120 V, 208 V, 240 V,
277 V, 380 V,
400 V, 415 V,
480 V, 600 V
1st Generation
0075 - 0.75 kW
0083 - 0.83 kW
009 - 0.90 kW
0113 - 1.13 kW
012 - 1.2 kW
0125 - 1.25 kW
Reminder: This nomenclature illustration is intended primarily to explain how a product part number is defined.
Not all voltages and/or wattage combinations are available. Please consult the Performance Data chart(s) for product availability.
Approved Locations
Electric convection air heaters are c UL us listed for the following hazardous locations:
(without built-in thermostat)
Class I, Div. 1 & 2, Groups A, B, C & D
Class I, Zones 1 & 2, Groups IIA, IIB, IIC
Temperature Code T2A 536°F (280°C),
T3 392°F (200°C)
For details of hazardous locations with potential for explosion, refer to the Canadian Electrical Code, Part 1, Section 18 or
National Electrical Code Articles 500 - 516.
Ruffneck™ and ProVector ® are registered trademarks of Themon Heating Systems, Inc.
Copyright © 2018. All rights reserved.
1
60
-
012
Hertz
50, 60
Phase
1, 3
Heater Kilowatts
0135 - 1.35 kW
0313 - 3.13 kW
018 - 1.8 kW
0333 - 3.33 kW
0226 - 2.26 kW
0347 - 3.47 kW
025 - 2.5 kW
0359 - 3.59 kW
0269 - 2.69 kW
036 - 3.6 kW
0301 - 3.01 kW
0476 - 4.76 kW
(with built-in thermostat)
Class I, Div. 1 & 2, Groups A, B, C & D
Class I, Zones 1 & 2, Groups IIA, IIB, IIC
Temperature Code T2A 536°F (280°C), T3 392°F (200°C)
-
T2A
I I B
T-Code
T2A - 536ºF (280ºC)
T3 - 392ºF (200ºC)
Hazardous Location
IIB, IIC
048 - 4.8 kW
0747 - 7.47 kW
050 - 5.0kW
076 - 7.6 kW
0528 - 5.28 kW
100 - 10.0 kW
0568 - 5.68 kW
0626 - 6.26 kW
0694 - 6.94 kW
Part No. 6348.Rev.18.04
-
T
T – Built-in room thermostat.
Add 'T' for T-stat.
A – Stainless steel cabinet
Nov 2018
ISO 9001
Printed in Canada
