- Page 1 ORIGINAL OPERATING AND INSTRUCTION MANUAL MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD rev. 2 CATEGORY II2H3+ 0705 TECNOEKA S.r.l. Via Marco Polo, n.11 - 35010 Borgoricco (Padova) Italy Tel. +39.049.9300344 – +39.049.5791479 Fax +39.049.5794387 www.tecnoeka.com...
- Page 2 Signature of a Representative of the Board of Directors (Lora Cristina) X:\Sgq\PRODOTTI\1 - FORNI\FORNO GAS\LEka\MANUALI D'USO - Forno gas - LEka\Lingua Inglese\Linea EKF\Instruction manual EKF 711G UD - EKF 664G UD - EKF 616G UD - GB - rev. 2.doc page. 2 __________________________________________________________________________________________...
-
Page 3: Table Of Contents
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD Index Descriptions and general warnings General warnings Data-plate and warning-plate Technical specifications General instruction (for installation technician) Storage Transporting the oven Unpacking the oven... - Page 4 TECNOEKA Srl _____________________________________________________________ use and instruction manual Maintenance General information Changing the lighting lamp in the cooking chamber Changing the door seal Cleaning the fans Resetting the thermal breaker safety device Possible faults Wiring layout TECHNICAL ASSISTANCE AND ORIGINAL SPARE PARTS Spare parts list Informations to the consumers The Warranty...
- Page 5 Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD Note 1: The information provided in this manual are valid only for the oven’s models listed in the cover and for the country whose initials are therein indicated with the category of membership.
-
Page 6: Descriptions And General Warnings
TECNOEKA Srl _____________________________________________________________ use and instruction manual 1. Description and general warnings The model convector oven bears (EKF616GUD - EKF664GUD - EKF711GUD) an official CE mark, issued by a Notified Body, entrusted with and responsible for evaluating the observance of the essential requirements specified by Gas Directive 2009/142/EC. -
Page 7: Data-Plate And Warning-Plate
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD 1.2 Data-plate and warning-plate The technical data-plate (Fig.1) and the plate with the installation warnings (Fig. 2) are permanently and visibly fitted on the rear panel of the oven. An additional plate – to be removed with all packing material –... -
Page 8: Technical Specifications
TECNOEKA Srl _____________________________________________________________ use and instruction manual 1.3 Technical specifications External overall dimension L x D x H 935 x 980 x 1070 mm 1.1.1.1.1.1.1.1 Weight 118 Kg Nominal thermal capacity 13,50 kW Tray maximal load GN1/1-600x400mm 4 - 2 kg Total load GN 1/1-600x400mm 28 - 12 kg ISO 7-1 gas union... -
Page 9: Storage
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD 2.1 Storage If the appliance has been stored in a warehouse at a temperature below 0°C (min. allowed is – 5°C), it should be brought to a temperature of at least +10°C before it is turned on. - Page 10 TECNOEKA Srl _____________________________________________________________ use and instruction manual Type A Installation: drawing the comburent air and discharging flue gases directly into the installation room. This installation requires the working environment to be kept wholesome by emptying the foul air and drawing fresh air through wall fans or extraction equipment. Type B Installation: installation required under extraction equipment.
-
Page 11: Gas Connection
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD Installation / connection layout WATER OULET TUBE (DN 30) SOFTENED WATER INLET (THREADED ELECTROVALVE 3/4") STEAM EXHAUST CABLE GLAND FOR POWER SUPPLY... -
Page 12: Electrical Connection
TECNOEKA Srl _____________________________________________________________ use and instruction manual Connection to the gas supply line must be made by using rigid or flexible pipes (maximum length 1,5m) , exclusively in metal, with diameters in proportion to the power of the appliance and the length of the pipe route. Make sure that the pipe does not pass close to the hot areas and that it is not subjected to torsion and traction stresses. -
Page 13: Thermal Breaker Safety Devices
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD must be at least 30 cm height difference between the drain pipe of the appliance and the drain point in order to assure regular water drainage. -
Page 14: Injector Replacement And Adjustment Of Primary Air
TECNOEKA Srl _____________________________________________________________ use and instruction manual Measure the connection pressure: if this value is not in the range shown in table 2 and it cannot be brought within these values by adjusting the pressure reducers of the gas supply system, definitive start-up of the appliance is quite impossible. -
Page 15: User Instructions
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD WARNINGS! After every adaptation to a new gas, make sure of the following: Using an indelible adhesive, apply the data referring to the new installation on the technical data-plate or apply a new data-plate to identify the current state of the gas regulation. -
Page 16: Residual Risks
TECNOEKA Srl _____________________________________________________________ use and instruction manual 4.1.1 Residual risks After a cooking operation, open the door cautiously, to avoid a violent outflow of heat which could cause burns. While the oven is in operation, pay attention to the hot zones (marked on the appliance) of its external surfaces. -
Page 17: First Ignition
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD Warning lights Programmer warning light Adjustment thermostat “end of cooking” warning light Automatic humidifier “no Gas” warning light warning light (for ovens providing this option) “Reset”... -
Page 18: Door Device
TECNOEKA Srl _____________________________________________________________ use and instruction manual - Turn the knob of the “end of cooking” programmer on the symbol or on the chosen time. - Turn the knob of the thermostat on the corresponding temperature value. - Turn the knob of the “automatic humidifier” on the corresponding chosen value. When the time is up, the oven turns off automatically. -
Page 19: Cleaning
Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD 5. Cleaning 5.1 General cleaning Before performing any cleaning on the appliance, disconnect the power supply (act on the safety magnetic circuit breaker) and water supply (close the water cock). Let it cool completely. -
Page 20: General Information
TECNOEKA Srl _____________________________________________________________ use and instruction manual Should you wish to use specific products on the market, these must comply with the cleaning requirements set out in the “General information” paragraph”. It is worth remembering that the counter supporting the appliance or the floor surrounding the area where the appliance is should also be cleaned without using acid corrosive substances (e.g. - Page 21 Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD 6.5 Resetting the thermal breaker safety device This device is accessed by removing the left side and/or back of the appliance. The device is reset by pressing hard the relevant button.
- Page 22 TECNOEKA Srl _____________________________________________________________ use and instruction manual 6.7 Wiring layout Power supply terminal board V1-V2 Radial motorised ventilators Safety thermostat Tangential motorized ventilator Oven thermostat C1-C2 Capacitors “End of cooking” programmer Gas card Automatic humidifier Relay 230/12V transformer Ignition electrode Lighting lamp Detection electrode Door microswitch...
- Page 23 Convection gas oven _ rev. 2__________________________ MODD. EKF 711G UD – EKF 664G UD – EKF 616G UD 7. TECHNICAL ASSISTANCE AND ORIGINAL SPARE PARTS Before leaving the factory, this appliance was tested and set up by expert, specialised personnel, to ensure best operating results.
- Page 24 TECNOEKA Srl _____________________________________________________________ use and instruction manual 9. The Warranty Your appliance is covered by warranty. The seller will replace or repair (and his decision will be final), free of charge for the customer, only those parts that are defective due to a manufacturing fault on condition that, under penalty of forfeiture: ...
