2 Basic Gauge Operations

Power on the Gauge

To power on the TKG250 thickness gauges follow these steps:
1. Press and hold the F1 key for more than 3 seconds. The power symbol is under
the F1 key printed on the keypad as shown below.
Power symbol
under the F1 key
2. The company information screen will appear on the display screen of the
thickness gauge.
3. The next screen that appears automatically is the Xducer (transducer) selection
screen, also referred to as Home screen in the manual.
4. Use the up and down arrow keys to select a transducer and press OK key. (Please
note, the transducer selection will automatically display the transducer last used
prior to shut off.) The following default transducer choices are available:
USER
DC110 1.0MHz
DC175 1.0MHz
DK250 2.0MHz
DC250 2.0MHz
DK525(s) 5.0MHz
DC525 5.0MHz
DK550 5.0MHz
DC550 5.0MHz
DK537 5.0MHz
DC537 5.0MHz
DHT537 5.0MHz
DK718 7.5MHz
DK1025 10.0MHz
DC1025 10.0MHz
5. Press F1 to select the Setup option.
6. Press F2 to select the Reset option.
7. Press F3 to select the Bklite option.
5.0MHz
TKG250 Ultrasonic Thickness Gauge
11
