Summary of Contents for Extech Instruments TH10
- Page 1 Page 1 of 11 Model TH10 Software Help Guide mhtml:mk:@MSITStore:C:\Program%20Files%20(x86)\Extech%20Instruments\TH10A\H... 8/30/2021...
-
Page 2: Software Introduction
The TH10 software allows the user to program the logger to record temperature in Fahrenheit or Celsius and to download the data for viewing and graphing. This version of software operates with the TH10 model that has a serial number starting with “A”. System Requirements: Windows 7, Windows 8.1, and Windows 10... - Page 3 Page 3 of 11 Install Datalogger Software Install the supplied Windows PC Datalogger Software by placing the supplied program disk in the PC CD-ROM drive, or by downloading the program from the Extech.com web site. If the installation program does not automatically open and provide on-screen prompts, double click the ExtechInstaller.exe program located in the root folder.
-
Page 4: Operation
Page 4 of 11 Main Menu The main menu bar for the software appears as follows: Open a saved graph file Save recorded data (Real Time or Saved Data) as a IMTR (graph) or CSV (Data) file Real time measurement (Click to Start and Click to Stop) Download the recorded data from the logger Datalogger Setup (Real Time and Datalogger) Help... - Page 5 § Start Mode: The MANUAL and INSTANT select buttons allow the user to start data logging immediately when the Setup window is exited (INSTANT), or at a later time (MANUAL). § SAMPLE RATE: This pull-down menu instructs the TH10 to log readings at a specific interval rate. Settings: 2s to 30s, 1m, 5m, 15m, 30m, 1hr, 5hr, 12hr, 24hr §...
-
Page 6: Real-Time Setup
§ TEMPERATURE UNIT: Selects the Temperature units of Celsius or Fahrenheit. Once the changes have been made, click on the SETUP button to save them. Press the DEFAULT button to set the TH10 back to factory default conditions. Press the CANCEL button to abort the setup. -
Page 7: Real-Time Measurements
Page 7 of 11 Real-Time Measurements Set up for Real-Time recording in the logger setup prior to running the unit in Real-Time mode. Click the Real-Time icon on the menu bar to Start logging in Real time while the logger is attached to the PC. Click the Real-Time icon again to Stop the logging session. -
Page 8: Data Download
Excel. Note: The data recorded by the TH10 logger is always saved in Degrees C. If you want the data to be printed and saved as a file to the PC in Degrees F, the Logger setup setting for temperature must be set to Fahrenheit. - Page 9 Page 9 of 11 mhtml:mk:@MSITStore:C:\Program%20Files%20(x86)\Extech%20Instruments\TH10A\H... 8/30/2021...
- Page 10 To Open a saved CSV formatted file, Use Windows Explorer to locate the file and open with Excel or Notepad. Note: The data recorded by the TH10 logger is always saved in Degrees C. If you want the data to be printed and saved as a file to the PC in Degrees F, the Logger setup setting for temperature must be set to Fahrenheit.
- Page 11 Page 11 of 11 Graph Operations Graph – Print Data To print the saved Graph data, open a saved Graph data file (.IMTR) and Right-Click anywhere in the graphing window. Select Print. To print the saved logger data in a table format, Open the saved data file (.CSV) in Excel or other word processor and print from that application.
