Foscam FI9816P Quick Installation Manual

Quick Installation Guide
Indoor HD Wireless IP Camera with P2P
Model:FI9816P
Black White
Foscam Digital Technologies
"Foscam" App download
V1.0
EE200470
Package Contents
IP Camera Power Adapter Resource CD Ethernet Cable
Quick Installation Guide
Indoor HD Wireless IP Camera with P2P
Model:FI9816P
Black White
Mounting Bracket Wi-Fi Antenna Quick Installation Guide Security Warning Card
Security Warning
Foscam cameras require good security practices to
safeguard your privacy. You can help protect your camera
by changing the default username and/or password.
You should update your camera regularly at
http://www.foscam.us/firmware.html. Make sure your
camera has the latest firmware installed for your specific
camera model.
1
Hardware Introduction
Physical Description
Speaker
LENS
Infrared LED
Antenna
Microphone
AUDIO ANT
DC 5V Network light
LAN
Power
OU T IN WPS SD
Output Micro SD Card Slot
Input
Mounting Port Reset Button
WPS
Power light
The Information of Network Light Status:
Network Light Description
Off No Wi-Fi connection
Flashing every 0.2 seconds EZLink takes effect (default)
Flashing every 0.4 seconds WPS is connecting
Slow Flash once per second Wi-Fi connected
Constant for 3 seconds Reset to take effect
Hardware Connection
AUDIO ANT
DC 5V
OU T IN WPS SD
WPS
1. Install wireless antenna and position upright.
2. Connect the power adapter to the camera.
3. Turn on your wireless router.
Before you start, please note:
Make sure your smartphone is located near the camera.
Do not use an ethernet cable to connect the camera if you
want to use a wireless connection.
Make sure smartphone is connected to your wireless router.
2

Access the IP Camera

by Smart Phone
1. Download and install the latest Foscam App named Foscam.
Two ways:
Scan the QR code of the Quick Installation Guide front cover
to enter the download page, download and install Foscam
App.
Go to App Store or Google Play store to search "Foscam" by
Foscam, download and install Foscam App.
The App icon will be displayed after successful installation:
Please Note:
If you are directed to a link for both iOS/Android after you have
scanned the QR code, click on the link to be directed to the
relevent App store.
