LEDS

LEDs
The groov Box's LEDs use color and blinking to show status information.
STOR
WLAN
USER
TEMP
SPEED
LINK ACT
64
groov Box User's Guide for GROOV AT1
LED What it shows
Hard drive activity
Wireless network connection
status and network activity
Not used
BATT Battery status
Temperature status
FAN Fan status
SYS groov Box status
PWR Power to Box
Ethernet link speed
Ethernet network activity
Color
Blinking green Activity on hard drive
Hard drive is being restored to factory
Blinking orange
defaults
groov Box is disconnected from the wireless
Off
LAN.
groov Box is connected to the wireless net-
Green
work
Blinking green Wireless LAN activity
n/a n/a
Green Battery 90% Charged
Blinking green Battery charging
Outside voltage range. BIOS may be cor-
Red
rupted. Contact Product Support.
Green Temperature OK
Red Temperature outside operating range
Green Fans are operating properly
Red One or both fans have failed
Off groov Box is turned off
Green groov Box is turned on
Blinking green groov Box is booting up
Blinking orange groov Box is shutting down
Off No input power
Green Good input power
Red Input power outside normal range
Off 10 Mbps
Green 100 Mbps
Orange 1000 Mbps
Off No Ethernet link
Green There is an Ethernet link, but no activity
Blinking green There is a link and activity
What it means
