AEMC 6240 User Manual

Spring loaded 10a test probes
Hide thumbs Also See for 6240:
Table of Contents

Advertisement

Quick Links

Download this manual
„ Spring loaded 10 a teSt probeS
E N G L I S H
User manual
0.561.8187
information@itm.
www.
.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6240 and is the answer not in the manual?

Questions and answers

Related Manuals for AEMC 6240

Summary of Contents for AEMC 6240

  • Page 1 „ Spring loaded 10 a teSt probeS E N G L I S H User manual 0.561.8187 information@itm. www. .com...

  • Page 2: Degree Of Pollution

    ENGLISH thank you for purchasing our spring loaded 10A test probes. these test probes are designed for use with aeMc Micro-ohmmeters Model 6240 and 6250 or equivalent. ® For best results from your instrument: „ read these operating instructions carefully, „...

  • Page 3: Table Of Contents

    cONtENtS 1. INtRODUctION............................ 3 1.1. Pistol test probe ........................4 1.2. SPRING LOADED Test probe ....................5 2. USE ................................ 6 3. SPEcIFIcAtIONS ..........................7 3.1. Environmental conditions ......................7 3.2. MECHANICAL SPECIFICATIONS .................... 7 3.3. Electrical safety ........................7 4.

  • Page 4: Pistol Test Probe

    1.1. PIStOL tESt PRObE probe protection cap. retractable probes to make contact at the measurement point. red spot that identifies the voltage probe (p). guard. under the housing, spare cap. Screw-on spaded lugs for connection to the instrument. one with a red sleeve for the voltage and one with a black sleeve for the current.

  • Page 5: Spring Loaded Test Probe

    1.2. SPRING LOADED tESt PRObE probe protection cap. retractable and rotating probes to make the contact at the measurement point. red spot that identifies the voltage probe (p). guard. under the housing, spare cap. Screw-on spaded lugs for connection to the instrument.
  • Page 6 „ place the voltage probes (identified by red spots) as close as possible to one another. „ during the measurement, hold the test probes firmly in contact with the object being measured. For details of the measurement configuration, technical specifications and error messages, refer to the user manuals of the 6240 or 6250. 0.561.8187 information@itm.

  • Page 7: Specifications

    3. SPEcIFIcAtIONS 3.1. ENvIRONMENtAL cONDItIONS indoor use. operating range -10 °c to +55 °c and 10 % to 85% rh Storage range -40 °c to +70 °c and 10 % to 90% rh degree of pollution altitude < 3000 m 3.2.

  • Page 8: Maintenance

    4. MAINtENANcE the manufacturer cannot be held liable for any accident that occurs following a repair not performed by its repair center. 4.1. cLEANING disconnect the accessory completely. use a soft cloth, dampened with soapy water. rinse with a damp cloth and dry rapidly with a dry cloth or forced air.
