Summary of Contents for Viega 6176
- Page 1 Citaplex drain/overflow Instructions for Use Model Year built: 6176 from 06/2015 en_INT...
- Page 2 Citaplex drain/overflow 2 from 15...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview 2.2.2 Technical data Handling Assembly information 3.1.1 Mounting conditions 3.1.2 Installation dimensions 3.1.3... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e. -
Page 6: Product Information
The drain/overflow is suitable for standard bathtubs with the drain on the head end. Detailed information regarding all bathtub models and the corre- sponding Viega drains / overflows can be found in the catalogue or on the Internet. Citaplex drain/overflow... -
Page 7: Product Description
Product information Product description 2.2.1 Overview 12 13 14 15 16 Fig. 1: Component overview valve plug with fixing chain fixing screw valve top double seal drain unit seal sliding ring union nut overflow pipe 10 - sleeve 11 - overflow unit 12 - profile seal 13 - fixing flange 14 - rosette... -
Page 8: Technical Data
Product information 2.2.2 Technical data Drainage capacity (at an accumu- The drainage capacity depends lation height of 300 mm) on the odour trap used. The overflow capacity depends on Overflow capacity (at an accumu- the odour trap used. lation height of 60 mm) Diameter of bathtub drain hole 52 mm Threaded drain unit... -
Page 9: Handling
Handling 3 Handling Assembly information 3.1.1 Mounting conditions The following requirements exist for the mounting of the drain / over- flow: The bathtub is installed. The drainage line is installed all the way to the bathtub. The underside of the bathtub is accessible. 3.1.2 Installation dimensions 120 - 240... -
Page 10: Assembly
Handling Material The following material must be purchased separately and must be avail- able during mounting: odour trap Assembly 3.2.1 Mounting overflow Proceed as follows to the mounting of the overflow: Push the rubber sleeve onto the pipe of the overflow unit. The lower edge must be flush with the edge of the overflow pipe. -
Page 11: Mounting The Drain
Handling 3.2.2 Mounting the drain Proceed as follows to mount the drain: Place the profile seal in the recess of the drain unit. Mount the drain unit with profile seal on the drain opening of the bathtub from below. Fit the valve top in the drain opening. Place the fixing screw in the drain unit and tighten using a flat-blade screwdriver. -
Page 12: Connecting The Wastewater System
Handling Hold the pipe of the overflow unit parallel to the overflow pipe and mark the positions where the drain and the overflow should be con- nected. Maintain an insertion depth of at least 15 mm! Cut the overflow pipe to the marked length and, if necessary, deburr. -
Page 13: Mounting Equipment Set
Handling 3.2.5 Mounting equipment set Proceed as follows to mount the equipment set: Gently bend open the bow of the valve plug. Thread the eyelet of the chain onto the bow. Bend the bow of the valve plug back together. Hang the free eyelet of the chain onto the bottom hook of the fixing flange. -
Page 14: Leakage Test
Handling The valve plug can be inserted into the rosette for safe-keeping. 3.2.6 Leakage test The leakage test is only carried out as a visual inspection. Check drain/overflow fitting for visible leaks. Maintenance NOTICE! Risk of damage due to unsuitable cleaning agent. The following cleaning agents can damage chrome-plated surfaces and therefore may not be used: –... -
Page 15: Disposal
Handling Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Citaplex drain/overflow 15 from 15...
