vacon 500x
ac drives
user’s manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500X and is the answer not in the manual?

Questions and answers

Related Manuals for Vacon 500X

Summary of Contents for Vacon 500X

  • Page 1 500x ac drives user’s manual...
  • Page 2 500x SUMMARY OF VACON 500X PARAMETERS User Parameter Name Options Default Setting See Page Model Number Model dependent Read-only Software Rev 0.00-99.99 Read-only Rated Current 0.0-200.0 A Read-only Serial No. 1 0-65535 Read-only Serial No. 2...
  • Page 3 Keeper Input Cfg text string 4 (disabled) Keeper Max Scale 0-32000 1000 Keeper Save Time 00:00 - 23:59 0:00 Keeper Save Rate text string 0 (24 hour) Keeper Input 0-32000 Read-only Value 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 4 500x User Parameter Name Options Default Setting See Page Keeper Time Rate text string 1 (minute) Keeper Rec. Num 0-255 Read-only Active Kpr. Record 0-255 Read-only Keeper Units text string 1 (GPM) Ramp Select text string...
  • Page 5 Timer 1 Type text string 0 (On Delay) Timer 1 Signal text string 1 (Drv Fault) Timer 1 Time 0.0 - 320.0 sec 1.0 sec Timer 2 Type text string 0 (On Delay) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 6 500x User Parameter Name Options Default Setting See Page Timer 2 Signal text string 1 (Drv Fault) Timer 2 Time 0.0 - 320.0 sec 1.0 sec Drive Name text string serial number Config USB Mode text string...
  • Page 7 Seq Cntl 18 Bit 0-15 (hex control) 0x0000 Seq Cntl 19 Bit 0-15 (hex control) 0x0000 Seq Cntl 20 Bit 0-15 (hex control) 0x0000 Seq Cntl 21 Bit 0-15 (hex control) 0x0000 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 8 500x User Parameter Name Options Default Setting See Page Seq Cntl 22 Bit 0-15 (hex control) 0x0000 Seq Cntl 23 Bit 0-15 (hex control) 0x0000 Seq Cntl 24 Bit 0-15 (hex control) 0x0000 Seq Cntl 25...
  • Page 9 500x parameters vacon 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 10 SUMMARY OF VACON 500X PARAMETERS ........1...
  • Page 11 VACON 500X ULTRAFLEX OPTIONS ........
  • Page 12 1. INTRODUCTION 1.1 Product Overview The Vacon 500X UltraFlex AC drive provides an economical, powerful solution for a large array of industrial ® applications. It features remote communications capability (using Ethernet, Devicenet, Modbus ® Modbus TCP/IP protocols), a keypad for easy configuration, and standard NEMA 4X / IP66 and NEMA 12 / IP55 enclosures that eliminate the need for mounting in a separate enclosure.
  • Page 13 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 14 2. TECHNICAL CHARACTERISTICS 2.1 Interpreting Model Numbers The model number of the Vacon 500X UltraFlex drive appears on the shipping carton label and on the technical data label on the model. The information provided by the model number is shown below:...
  • Page 15 5.5 to 132 kW/7.5 to 200.0 HP models: Forced air (temperature-controlled external fan) 2.4 Electrical Specifications Input voltage Vacon 0500 models: 380-460 Vac, 3 phase, +/- 15% 4-132 kW/5-200 HP Line frequency 50 / 60 Hz ±2 Hz Source kVA (maximum)
  • Page 16 2.6 Dimensions and Weights Table 1 lists dimensions and weights for the Vacon 500x frame size 1, 2, and 3 models. Dimensions and weights for the Vacon 500x frame size 4 and 5 models are shown in Table 2 on page 17.
  • Page 17 1.38 (35) 1.69 (43) 1.13 (29) 0.88 (22) 5.60 (142) 7.24 (184) Weight 14.0 (6.35) 29.5 (13.38) 50.0 (22.68) lb (kg) Table 1: Dimensions and Weights for Frame Sizes 1 - 3 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 18 7.65 (194) 0.42 (11) 0.42 (11) 8.63 (219) 12.57 (319) 8.26 (210) 11.10 (282) Dimensions in (mm) (See Vacon 500x 0.53 (13) 0.20 (5) diagrams on pages 21 - 2.69 (68) 2.32 (59) 3.94 (100) 3.82 (97) 2.44 (62) 2.94 (75) 0.88 (22)
  • Page 19 18 series Figure 1: Vacon 500x Frame Size 1 Models 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 20 Figure 2: Vacon 500x Frame Size 2 Models Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 21 20 F (8) PLACES series M (2) PLACES N (3) PLACES Figure 3: Vacon 500x Frame Size 3 Models 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 22 F (8) PLACES series N (2) PLACES M(2) PLACES S (1) PLACES Figure 4: Vacon 500x Frame Size 4 Models Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 23 22 F (8) PLACES series N(2) PLACES M (2) PLACES S (1) PLACE Figure 5: Vacon 500x Frame Size 5 Models 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 24 ATTENTION 3.2 Installation Precautions Improper installation of the Vacon 500x drive will greatly reduce its life. Be sure to observe the following precautions when selecting a mounting location. Failure to observe these precautions may void the warranty! See the inside front cover of this manual for more information about the warranty.
  • Page 25 1891 0240 5 2302 3.4 Cover Assembly and Torque Specifications Figure 6 shows the locations of the Vacon 500x cover screws. The torque range for the Size 1 cover is 18- 26 in/lbs. Cover screw locations Cover screw locations Figure 6: Vacon 500x Cover Assembly and Screw Locations Torque specifications for control terminals and power terminals are listed in “General Wiring Information”...
  • Page 26 3.6 Conduit Usage The Vacon 500x drive in the NEMA 4x / IP66 enclosure is rated for 1000 psi washdown from 6 inches. To keep this rating, the use of a sealed conduit is required. The use of a Romex-type conduit will not prevent water entry into the enclosure.
  • Page 27 26 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 28 4. CONNECTIONS HAZARDOUS VOLTAGE • Read and understand this manual in its entirety before installing or operating the Vacon 500x AC drive. Installation, adjustment, repair, and maintenance of these drives must be performed by qualified personnel. • Disconnect all power before servicing the drive. WAIT 5 MINUTES until the DC bus capacitors discharge.
  • Page 29 4. Grounding must be in accordance with NEC and CEC. If multiple Vacon 500x drives are installed near each other, each must be connected to ground. Take care not to form a ground loop.
  • Page 30 Therefore, ensure that the voltage rating of the motor matches the applied line voltage. 4.3.2 Line Capacity If the source of AC power to the Vacon 500x AC drive is greater than 10 times the kVA rating shown in Table below, an isolation transformer or line reactor is recommended.
  • Page 31 4.3.6 Motor Lead Length VACON Plc recommends that the total lead length should not exceed the motor manufacturer’s guidelines. Line disturbance and noise can be present in motor wiring of any distance. As a rule of thumb, any non- inverter duty motor should have a reactor or filter added when the motor lead length exceeds 150 feet.
  • Page 32 “fast on” (spade) connectors for models up to 18.5 kW/30 HP, and on the terminal strip for models 30 kW/40 HP and larger. See page 33 for specific information about dynamic braking. Figure 7: Vacon 500x Power Terminals Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 33 It is necessary to provide fuses and a disconnect switch for the input AC line in accordance with all applicable electrical codes. The Vacon 500x AC drive is able to withstand a 150% overload for 60 seconds for heavy duty rating, and 120% overload for normal duty rating.
  • Page 34 Table 5: Fuse Ratings 4.5 Dynamic Braking The Vacon 500x AC drive is supplied with an integrated dynamic braking (DB) resistor, and is designed to have adequate dynamic braking for most applications. In cases where short stopping times or high inertia loads require additional braking capacity, install an external resistor.
  • Page 35 4.6 Terminals Found on the Vacon 500x Control Board 4.6.1 Description of the Control Terminals Figure 9 shows the control terminals found on the I/O board of the Vacon 500x AC drive. See page 15 specifications. Table 7 on page 36 shows how to use the control terminals for preset speeds.
  • Page 36 4.6.2 Typical Connection Diagrams for Digital Inputs Typical connection for 2-wire control Typical connection for 3-wire control Figure 10: Connections for 2-wire and 3-wire Control Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 37 (parameter 312) Preset frequency F10 (parameter 313) Preset frequency F11 (parameter 314) Preset frequency F12 (parameter 315) Preset frequency F13 (parameter 316) Preset frequency F14 (parameter 317) Preset frequency F15 (parameter 318) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 38 4.6.3 Typical Connection Diagrams for Analog Inputs Figure 12: Connections for Speed Potentiometer Figure 13: Connections for Process Signal Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 39 4.6.4 Typical Connection Diagrams for Analog Outputs Figure 14: Connections for Process Meters 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 40 5. OPERATION AND PROGRAMMING 5.1 Introduction The Vacon 500X AC drive is pre-programmed to run a standard, 4-pole AC induction motor. For many applications, the drive is ready for use right out of the box with no additional programming needed. The digital keypad controls all operations of the unit.
  • Page 41 If power is removed and reapplied, the memory will retain the last selected function. Table 1: Function of Keys in Operation Mode (Vacon 500x Running or Stopped) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 42 The display will show “stored” for one second indicating that the new value has been entered into memory. NOTE: The Vacon 500x unit allows you to view only those parameters that have changed. If you press keypad keys ENTER and PROGram simultaneously, only those parameters that have been changed from the factory defaults will be shown.
  • Page 43 Table 3: Function of Keys in Fault Mode 5.3 LCD Displays The Vacon 500x drive’s digital keypad display provides information such as source of drive control, status, mode, and access rights. 5.3.1 Control...
  • Page 44 The drive is not enabled because of time restrictions programmed into the Time TOD Inhibit of Day parameters. Table 4: Keypad Status States Table 5 shows Vacon 500x keypad warning messages that may appear during operation: Message Meaning DB Active The DB Resistor is being actively pulsed.
  • Page 45 44 CPU Warning A system error occurred in the software of the Vacon 500x. Mtr Measure An RS Measurement is armed or active. IR Active Valid IR communications are occurring. Seq Running The program sequencer functionality is active.
  • Page 46 801, Program Number 5.5.5 Viewing Parameters That Have Changed The Vacon 500x unit allows you to view only those parameters that have changed. If you press keypad keys ENTER and PROGram simultaneously, only those parameters that have been changed from the factory defaults will be shown.
  • Page 47 1. Make sure there is no load applied to the motor and that the motor shaft is free to spin without damage or injury. 2. Enter the Macro programming mode of the Vacon 500x keypad by pressing and holding the PROG key until the parameter “Appl Macro” appears on the keypad. This takes about two seconds.
  • Page 48 You can use a flash memory stick (sometimes called a jump drive, thumb drive, or flash drive) with the USB port on the Vacon 500x. In this way, software, program parameters and Keeper data can be stored easily. The file type for drive parameters is the same as used by PDA-trAC Plus with an extension of .tps.
  • Page 49 5.7.4 Reflashing the Vacon 500x Using the USB Port and a Flash Memory Device You may find it convenient to be able to reflash the Vacon 500x memory and load new software. This is possible to do via the USB port and a memory stick to which you have copied the software.
  • Page 50 10. Results of the reflash are shown in the display, and depending on the results, you will see different things. If the reflash is successful, the Vacon 500x software will show the normal Vacon 500x display. If unsuccessful, the following screen appears: The number after “Request Failed”...
  • Page 51 5.9.1 Enabling the Vacon 500x Based on Time of Day (TOD) The Vacon 500x includes two “enable” windows that can control when the drive is allowed to run during the course of a work day, Monday through Friday, and an additional “enable” window for weekends. To use this...
  • Page 52 This kind of functionality is often critical to coordinating the operation of more than just the motor driven by the Vacon 500x. You may even be able to eliminate the need for a PLC to control a complete operation, if you can utilize more of the built-in functionality of the Vacon 500x.
  • Page 53 It doesn’t matter if the analog input is controlling the Vacon 500x or not; the Vacon 500x is simply measuring the input and can transmit the condition of the signal associated with it.
  • Page 54 6. USING MACRO MODE AND GETTING A QUICK START A special Macro programming mode is available with the Vacon 500X series of AC drives. The Macro programming mode allows you to customize quickly the most common parameters for your application in the Level 1 group.
  • Page 55 This parameter (Special Program Number) provides a method of enabling hidden functions in the drive and storing parameters to the customer set. There are numerous options for this parameter, more fully described in Chapter 7, Vacon 500x Parameters. Please refer to the detailed description of parameter 801 options in Chapter 7, on page 87.
  • Page 56 Range: 1-65535 810 Language Default: English Level 2, Macro This parameter configures the language in which text strings will be displayed. The following data values may be assigned to this parameter:...
  • Page 57 Linear 2pc Skip Freq Band 0.2 Hz Skip Freq 1 0.0 Hz Restart Number Table 3: Fan with PI Application Macro (Core Factory Application from Table 1, plus the following parameters) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 58 Para. # Parameter Name Default See Page Restart Delay 60 sec Imet Config Current Out Imet Span 100.0% Imet Offset 0.0% DI1 Configure Preset 1 DI2 Configure Preset 2 DI3 Configure...
  • Page 59 Default See Page V/Hz Select Vector Rated Mtr Volt Model dependent Rated Mtr FLA ND rating Table 6: Vector Application Macro (Core Factory Application from Table 1, plus the following parameters) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 60 Para. # Parameter Name Default See Page Rated Mtr RPM 1750 rpm Motor RS Model dependent Power Factor Slip Comp Enable Find Mtr Data Not Active Filter FStator 8 mS Start Field En...
  • Page 61 T1/U, T2/V, or T3/W. 7. The Vacon 500x drive is preset to run a typical NEMA B 4-pole induction motor to a maximum speed of 60.0 Hz with both acceleration and deceleration times set to 5.0 seconds.

  • Page 62: Table Of Contents

    7.3 Description of Parameters Table 2 lists the Vacon 500x parameters in the order in which they appear in the keypad display. For each parameter, the table lists the default value and range and also describes the use of the parameter.

  • Page 63: Output Voltage

    Parameter 103, the Output Voltage parameter, displays the output voltage of the drive. Range: 0.0 to 200.0 A 104 Output Current Read-Only Levels 1,2 Parameter 104, the Output Current parameter, displays the output current of the drive. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 64: Drive Load

    500x parameters Range: -200.0% to 200.0% 105 Drive Load Read-Only Levels 1,2 Parameter 105, the Drive Load parameter, shows the percentage torque of the drive when operating below the knee frequency. It displays Load Torque if the frequency is below FKNEE, and displays Power if above FKNEE.
  • Page 65 This parameter sets the starting time that the drive is enabled to run if a Run signal is active. If equal to “Time Run Enable,” the function is disabled. (See “Enabling the Vacon 500x Based on Time of Day (TOD)” on page 50.)
  • Page 66 500x parameters Range: n/a 171 Reminder 1 Conf. Default = Disabled Level: 2 This parameter configures the reminder to measure the run time or total time before activating the reminder. The following data values may be assigned to this parameter:...

  • Page 67: Input Mode

    The following data values may be assigned to this parameter: Parameter Value Description Coast Drive will coast to a stop Ramp Drive will ramp to a stop using Decel #1 Disabled Stop key will have no function 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 68 Vin2 Vin2 terminal (configured by parameter 211) Vin1 6FS Vin1 terminal with 6x pulse train from a Vacon 500x, WFC, WF2 drive Vin1 48FS Vin1 terminal with 48x pulse train from a Vacon 500x, WFC, WF2 drive Vin1+Cin Sum of signal at Vin1 and the signal at Cin...
  • Page 69 0 ms, there is no software filtering of the analog input. A value above 0 ms causes the drive to filter the analog signal. Note that long filter times will create a delay in the drive response to signal changes. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 70: Min Frequency

    500x parameters Range: n/a 217 Trim Ref Enable Default = Disabled Level: 2 This parameter enables or disables trimming of the drive reference by an analog input and selects which analog input will perform the trimming function. Speed Reference = Main reference + (Trim % Factor) * (Analog in Percentage) * Max Frequency / 100%...
  • Page 71 Levels 2 (Clock) This parameter shows how many records have been saved by the Keeper. For detailed information about setting up Keeper parameters, see “Using the Keeper Data Log” on page 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 72: Accel Time

    500x parameters Range: 0 - 128 388 Active Kpr. Record Default: Read-only Levels 2 (Clock) This parameter shows the active Keeper record. For detailed information about setting up Keeper parameters, see “Using the Keeper Data Log” on page...
  • Page 73 DC injection braking may be used to stop the motor more quickly than is possible by either a ramp-to-stop or a coast-to-stop. The Vacon 500x drive allows DC braking to be initiated either when a digital input assigned to DC braking becomes true, when a specified frequency is reached, or when either of these events occurs.
  • Page 74 500x parameters Configures the frequency under which direct current will be applied to the drive when DC Inject Config is set to “DC on Freq.” If this parameter is set to 0.0, the parameter operates in the same way as “DC at Stop.”...
  • Page 75 SIO Cntl Word (904)FBus Read 5 (884)Status Word 2 (926) Ext Ref Freq 1 (905)FBus Write 1 (890)Cntl Word 2 (907) Ext Ref Freq 2 (906)FBus Write 2 (891)FBus Port Config (917) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 76: Voltage Boost

    500x parameters Range: 0 to 7 501 V/Hz Select Default: Linear Fxd Level 2 The V/Hz Characteristic Selection parameter determines the characteristic of the V/Hz curve and whether any boost will be applied at starting. The following data values may be assigned:...
  • Page 77 Once configured, the drive will accelerate or decelerate through the prohibited frequency band without settling on any frequency in the band. The Vacon 500x AC drive provides the capability to configure four prohibited frequency bands. Parameter 504 (Skip Freq Band), the Skip Frequency Band parameter, sets the width of the band above and below each of the prohibited frequencies set in parameters 505, 506, 507, and 508 (Skip Freq 1,2,3, 4).
  • Page 78 500x parameters Range: n/a 516 Slip Comp Enable Default: No Level 1,2 This parameter is accessible through Macro modes, or through parameter 501 (V/Hz Select) and choosing Vector mode. It is only visible if the drive is in a vector-capable mode; otherwise, it is hidden. The following...
  • Page 79 This option operates in the same way as “w/ LVT” except that the Line Voltage Tracker function of the Undervoltage Ride-Thru is not active. The Line Voltage will be estimated on powering up the drive. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 80 Default: Fixed Lvls Level 2 The Vacon 500x drive provides a Current Limit feature. With this feature enabled, the drive’s frequency is automatically reduced when operating in motoring mode to keep the measured torque within limits. When operating in regenerative mode, the output frequency can be automatically increased for the same reason.
  • Page 81 610 Timed OL Select Default: Std Ind 60s Level 2 Two parameters in the Vacon 500x work together to configure how the motor timed overload operates: parameter 510 (Rated Mtr FLA) and parameter 610 (Timed OL Select). Parameter 510 (Rated Mtr FLA) should be configured to the value on the nameplate of the motor. This value is used in calculating the percentage of current at which the drive is operating.
  • Page 82 500x parameters Range: 100 - 1001% 613 Max Regen Ramp Default: 300% Level 2 This parameter operates as a percentage of the longest ramp time. This time then defines the amount of time a deceleration to stop can take without causing a “Regen Timeout” fault. For example, if “Decel Time 1”...
  • Page 83 Level 2 This parameter sets the span of the Imet analog output. Range: 0.0%-90.0% 704 Imet Offset Default: 0.0% Level 2 This parameter sets the offset of the Imet analog output. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 84 Local ModeThe keypad is the control path for reference speed and control functions. SeqOut-000Programmed sequence step active. SeqOut- values are all status SeqOut-001outputs linked to a step in the program sequencer. SeqOut-010 SeqOut-011See “Using the Vacon 500x Program Sequencer” on page 98 for more information. SeqOut-100 SeqOut-101 SeqOut-110 SeqOut-111...
  • Page 85 Rem 1 GateA digital input has triggered the gate for Reminder #1. Rem 2 GateA digital input has triggered the gate for Reminder #2. Rem 3 GateA digital input has triggered the gate for Reminder #3. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 86 500x parameters Note that Alt Ramp and Alt Ramp2 work together to choose the ramp, based on the values in the following chart: AltRamp Ramp Chosen AltRamp2 Accel Time1 / Decel Time 1 Accel Time2 / Decel Time 2...
  • Page 87 (using parameter 799) will have a filename associated with parameter 794 (Drive Name). The complete drive serial number is composed of the data found in parameters 005 and 006, and is also found on the drive nameplate. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 88 This parameter allows you to select what kind of data you want to store in a flash memory device such as a thumb drive or memory stick. For more information on using a flash memory device with the Vacon 500x,...
  • Page 89 Range: 1-65535 810 Language Default: English Level 2, Macro This parameter configures the language text strings will be displayed in. The following data values may be assigned: Parameter Value English Spanish 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 90 Default: 100.0% Level 2 The Master / Follower Speed Ratio parameter allows the pulse train output of one Vacon 500x series drive (master) to be used to control the speed of up to 8 other follower drives. The output of each follower can be individually programmed, or trimmed “ON-THE-FLY”...
  • Page 91 Level 2 This parameter sets the high limit of the PID output. Range: 0.00-100.00% 858 PID Low Corr Default: 0.00% Level 2 This parameter sets the low limit of the PID output. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 92 860 PID Sleep Cfg Default: 0 Level 2 This parameter configures the conditions under which the Vacon 500x can turn off (sleep) once the external process loop has been completed. Refer to parameter 861 (PID Sleep Lvl ) for the sleep threshold.
  • Page 93 Level 2 (SIO) This parameter defines a watchdog timer that will require a valid communication in the specified time period while in SIO control. If the requirement is not met, a fault occurs. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 94 500x parameters Range: n/a 904 SIO Cntl Word Default: 0x0000 Level 2 (SIO) The SIO Control Word parameter allows control of the drive through Modbus communications. The following bits are used with this parameter: When Set to 1 Signifies...
  • Page 95 The following bits are used with this parameter: When Set to 1 Signifies When Set to 1 Signifies RB Output R1 Output R2 Output DO1 Output DO2 Output RA Output 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 96 500x parameters 914 Vmet Status Range: 0.00-100.00% Default: Read-Only Level 2 (SIO) 915 Imet Status Parameter 914 provides the output percentage applied to the Vmet terminal; parameter 915 provides the output percentage applied to the Imet terminal. Range: n/a...
  • Page 97 953 Seq Cntl 24 954 Seq Cntl 25 These parameters each provide a 15-bit binary status display. “Using the Vacon 500x Program Sequencer” on page The following bits are used with each of these parameters: Bit 0-3=Speed Selection Bit 4-5=Ramp Selection...
  • Page 98 978 Seq Count 24 979 Seq Count 25 These parameters configure the time, number of pulses, or analog level of sequencer steps 1 through 25, respectively. See “Using the Vacon 500x Program Sequencer” on page 980 Seq Decision 1 Decision 981 Seq...
  • Page 99 7.4 Using the Vacon 500x Program Sequencer The Vacon 500x AC drive offers functionality that allows users to program up to 25 independent operation states of the drive. This functionality is called the “program sequencer” because it allows the drive to sequence through the operation states programmed by the user.
  • Page 100 Keypad Control (Activation) of the Vacon 500x Program Sequencer When activating or controlling the Vacon 500x Program Sequencer from the keypad, pressing the FWD key commands the drive to cycle through the programmed states of the sequencer one time only (one-shot operation).
  • Page 101 Vacon 500x Sequencer Dwell Functionality The Vacon 500x sequencer can dwell, or pause, in a state and disregard any command to advance to the next state. This can be done in two different ways, and both methods can be used at the same time: •...
  • Page 102 Vacon 500x Sequencer Speed Selection Table 4 gives more information on the speed selection options available in the Vacon 500x sequencer by programming bits 0, 1, 2, and 3 of each state’s control parameter. The options include any Preset Speed, Max Frequency, or allowing the reference to be determined in the normal Vacon 500x control path.
  • Page 103 Sequencer Output Configuration The Vacon 500x Program Sequencer allows digital outputs to be activated during states of the sequencer. This function could be used to activate other devices in a system or to signal to an operator when a part of the sequence is active.
  • Page 104 500x parameters Bits 10-12 of the state’s control parameter determine the control selection configuration for that state of the sequence. See the following chart for control selection options: Binary Value Definition The drive will be stopped while in a state configured with this control selection.
  • Page 105 1010 and 1011. If the AND (1010) configuration is selected, then all bits set in the count parameter must have the corresponding drive state occur for advancement to the next 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 106 Figure 19: Seq Count Parameter’s Drive State Bit-Packed Definition 7.4.5 Sequencer Decision Configuration The Vacon 500x sequencer has up to five possible decision states available. This allows users to program a decision into the sequence. Decisions are programmed through five parameters: Seq Decision 1, Seq Decision 2, Seq Decision 3, Seq Decision 4, and Seq Decision 5.
  • Page 107 A sample operate screen (where the sequencer is in state 1) is shown below: Q 1 : S t o p p e 0 . 0 H z + 0 % 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 108 500x parameters When the sequencer is running, a warning, “Seq Running,” will flash on the screen to indicate that the drive control state may change without user input. For example: Q 1 : S t o p p e...
  • Page 109 Seq Count 2 2 minutes = 120 seconds No outputs/REV/DI Value/Primary Ramp/Preset Seq Cntl 3* 00101100001 Speed 1 Seq Count 3 Seq1 active Table 10: Required Parameter Settings for Sample Sequencer Program 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 110 500x parameters Worksheet for Sequencer Program Setup (remove and make 2-sided copy for each machine needed) Machine Number ________ Hex Value Ramp Output Direction See App. State Duration Selecti Speed Selection Configuration Selection A, page Step Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 111 500x parameters vacon 110 Machine Number ________ Output Ramp Direction Hex Value Configuratio State Duration Select Speed Selection Selection See App. A, page 119 Step Notes: 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 112 For questions about accessing fault codes, and for advanced troubleshooting problems, please contact VACON Plc (web site: http://www.vacon.com). Table 1 shows the fault codes that may be displayed during Vacon 500x AC drive operation, along with suggestions for recovering from the fault condition.
  • Page 113 Check for mechanical binding and shock loading. Note: Shaded faults are auto-resettable, except where noted. Table 1: Vacon 500x Fault Codes 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 114 Modbus comm. parameter 903 (SIO exceeds the time set in Timer) as needed. parameter 903 (SIO Timer). Note: Shaded faults are auto-resettable, except where noted. Table 1: Vacon 500x Fault Codes Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 115 The encoder is not functioning 2 or 3 Consult factory. properly. Note: Shaded faults are auto-resettable, except where noted. Table 1: Vacon 500x Fault Codes 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 116 Note: Shaded faults are auto-resettable, except where noted. Table 1: Vacon 500x Fault Codes Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
  • Page 117 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 118 Part Number: X5RKWM This Remote Keypad kit can be used with a Size 3, 4, or 5 Vacon 500x model to allow the keypad to be mounted in another location. The kit comes with an adapter assembly to allow the existing keypad to be remotely mounted.
  • Page 119 500x ultraflex options vacon 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 120 APPENDIX: BINARY-HEXADECIMAL CONVERSION The Vacon 500X UltraFlex AC drive utilizes hexadecimal numbers to display and store the binary values of some parameters. These parameters are read and written as four-digit hexadecimal values. The following table shows the binary values that correspond to the sixteen hexadecimal values. The binary values are divided into four columns so you may more readily see which bits of the status or control words are affected by the binary values.
  • Page 121 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 122 Chambersburg, PA 17201 USA hereby declare that the products: Product Name: Vacon 500X Series Model Number: 0009 5, 00012 5, 0016 5, 0023 5, 0031 5, 0037 5, 0043 5, 0061 5, 0071 5, 0086 5, 0105 5, 0140 5, 0168 5, 0205 5, 0240 5...
