ON Semiconductor STK404-120NGEVB User Manual

STK404-070NGEVB,
STK404-120NGEVB,
STK404-140NGEVB
STK404-000N Series
Evaluation Board
User's Manual
Thick-Film Hybrid IC for use used in from 60 W to 180 W
 1ch class AB audio power amplifiers.
This Evaluation Board User's Manual describes the set-up
and use of the STK404−000N Series Evaluation Board for
SANYO Semiconductor (An ON Semiconductor Company).
Thick-Film Hybrid IC for use in from 60 W to 180 W
 1ch class AB audio power amplifiers devices
STK404-070N-E, STK404-120N-E and STK404-140N-E.
For data sheets and additional on these devices, please
visit the ON Semiconductor website at www.onsemi.com.
(100 mm  70 mm  1.6 mm,
Phenol 1-layer Board)
Figure 2. STK404−070NGEVB
Table 1. SELECTION GUIDE
Output1 (10%/1 kHz)
Output2 (1%/20 Hz to 20 kHz)
Maximum Rating V max (no sig.)
CC
Maximum Rating V (6 W)
CC
Recommended Operating V
CC
Package Size
 Semiconductor Components Industries, LLC, 2013
June, 2013 − Rev. 0
EVALUATION BOARD FOR STK404−070N, −120N, −140N
(100 mm  70 mm  1.6 mm,
Phenol 1-layer Board)
Figure 3. STK404−120NGEVB
STK404−070N−E
60 W  1ch
40 W  1ch
46 V
39 V
(6 W) 30 V
44.0  25.6  8.5 (mm)
EVAL BOARD USER'S MANUAL
Figure 1. STK404−000N Series Evaluation Board
Figure 4. STK404−140NGEVB
STK404−120N−E
120 W  1ch
80 W  1ch
65 V
59 V
41 V
46.6  25.5  8.5 (mm)
1
http://onsemi.com
(100 mm  70 mm  1.6 mm,
Phenol 1-layer Board)
STK404−140N−E
180 W  1ch
120 W  1ch
78 V
73 V
51 V
59.2  25.5  8.5 (mm)
Publication Order Number:
EVBUM2197/D
