MG32LRF - User's Quick Reference Guide
Off Light (red)
On = Disarmed
Off = System armed
Power and Rx/Tx Light
On = Power on
Off = Power off
Fast Flash = Transmission/
reception in progress
Slow Flash = AC loss on keypad
StayD (grn)
On = StayD mode enabled
Slow Flash = Low battery on keypad
= Press once + [
MASTER
] for Quick Menu
CODE
Programming)
Zone Display:
The numbers [1] to [32] correspond
to zones 1 to 32 respectively. Open
or entry delay zones are illuminated,
and flash in alarm.
TO ARM
...
WHEN LEAVING
To Regular Arm:
1. Close all zones in the desired partition.
2. Press [ ].
ARM
3. Enter your [
ACCESS CODE
* If needed, press button(s) corresponding to desired partition(s). For two partitions, press the other key after the confirmation beep.
K O
EYPAD VERVIEW
Partition 1 Status Partition 2 Status
MG32LRF Keypad
A D
RMING AND ISARMING
WHEN STAYING
To Stay Arm:
1. Press the [
2. Enter your [
].
To Sleep Arm:
1. Press the [
2. Enter your [
To Disarm:
[ ] + [
OFF ACCESS CODE
Arm (red), Sleep (yel), Stay (grn):
On = Partition armed
Off = Partition disarmed
Flash = Exit Delay
Fast Flash* = Exit Delay (final 10
sec.)
Fast Flash* = Partition in alarm
* Audible Indicators:
Continuous beep = Alarm,
Variable beep = Fire alarm
Intermittent beep = Beginning of exit delay
Fast beep = Final 10 sec. of exit delay
lnfo Key
Refresh display to see all open
zones.
[ ] Trouble display
TBL
ON = Trouble(s) occurring
[ ] Alarm memory display
MEM
ON = Alarm(s) occurred
[ ] Bypass programming
BYP
ON = Zone(s) bypassed
TO ARM
...
] key.
STAY
]*.
ACCESS CODE
] key.
SLEEP
]*.
ACCESS CODE
]*
