Start Up Instructions phyCORE-TC1775

Start Up Instructions

Thank you for choosing a module from the phyCORE product line.

These modules were designed especially for OEM implementation in industrial

products. Development Boards, which supply the phyCORE with the required

operating voltage and provide connectors for the most important interface

signals were developed to facilitate start up and to enable the user to become

familiar with the module

These start up instructions show the steps necessary for a successful start with

the phyCORE-TC1775 mounted on the phyCORE Development Board for

TriCORE. The connectors and components described in the text refer to the

figure below.

Figure 1:

phyCORE-TC1775 on the phyCORE Development Board Tricore

(Note: The figure shows the debugCORE-TC1775 module)

Date: 01.08.02

Techn. Hotline Europe: +49 (6131) 9221-31

http://www.phytec.de

Techn. Hotline America: 1-800-278-9913

http://www.phytec.com

1/2

LAN-014e_1

Table of Contents

Need help?

Do you have a question about the phyCORE-TC1775 and is the answer not in the manual?

Page 1 These start up instructions show the steps necessary for a successful start with the phyCORE-TC1775 mounted on the phyCORE Development Board for TriCORE. The connectors and components described in the text refer to the figure below.
Page 2 5. Connect the included 5 V voltage adapter to socket X1 on the Development Board. All three "power-good" LED‘s should illuminate. 6. The phyCORE-TC1775 is now ready to be connected to the debugger of your software development environment. Start Up with the On-Chip Bootstrap Loader of the TriCORE-TC1775 1.
