Terminate Floor Input Wiring
The EC1500 with five (5) output control boards can regulate up to 40 floors. The EC1500 and EC2500 do not
have floor status with supervision.
Cut View of EC1500B
Floors 1 - 8
Door Inputs - A Common
1 2 3 4 5 6 7 8
Call Button Status
2 of 40
Normally Open
Dry Contact
N.O.
Relay
Floor monitoring inputs (separate dry contacts) provided by 3
KI-00136E-07-11
Keyscan Inc. – Technical Guide (PC109x - 04.15)
Figure 32 – Terminate Floor Input Wiring EC1500B
40 Floor Status Inputs
Floors 9 - 16
Floors 17 - 24
Common
RTE Inputs - B AUX Inputs - C
1 2 3 4 5 6 7 8 1 2 3
Call Button Status
13 of 40
Normally Open
Dry Contact
N.O.
Relay
Floors 25 - 32
Common AUX Inputs - D
4 5 6 7 8 9 10 11 12 13 14 15
Call Button Status
24 of 40
Normally Open
Dry Contact
N.O.
Relay
rd
party elevator company.
Floors 33 - 40
Common AUX Inputs - E
16 17 18 19 20 21 22 23 24
