Figure 24 - Terminate Lock Wiring Ca8500B - Keyscan CA250B Technical Instructions

CA850 0B
Control Board
Cut Vie w
connects to CONTROL 1
-
TAMPER TB3
SWITCH
CTS
DTR
DCD
RD
TD
GND
RS-232 (COM4)
Ensure all lock
hard wa re complie s
with federa l, state/
provincial, and
municipal fire cod es.
KI-00128E-10-14
Keyscan Inc. – Technical Guide (PC109x - 04.15)
Figure 24 – Terminate Lock Wiring CA8500B
OCB-8
OUTPUT
CONTROL
BOARD
OCB8
P C1102
Not e
TB4
DIP switches set
RELAY
rela ys for normal or REV.
reverse, as
NORMAL
indi cated by the
arro ws.
OCB-8 ribb on cab le
terminal.
S1
H1
red stri pe
OCB-8 powere d
TB1
through rib bon
cable with J1
Relay P ower set
on ACU.
+
Diode
1N400 4
-
Com
K8 K7 K6 K5
Door Door Door
Output Output Output
8 7 6
(DIP (DIP (DIP
Switch 8) Switch 7) Switch 6)
Door
Door Door
Output Output Output
1 2 3
(DIP (DIP (DIP
Switch 1) Switch 2) Switch 3)
K2
K1 K3 K4
Door # 1
Door Strike
- Fail Secure -
to N.O.
-
Gro und
DC
Lug Sup ply
KEYSCAN
INC.
TB3
Door
Output
5
(DIP
Switch 5)
GND
12V
Door
EXT
Output
J1
4
(DIP ACU
Relay
Switch 4)
Power
TB2
LE D ON =
RELA Y
E NE RGIZ ED
12 VDC+
36
