Appendix B – Indala
Readers
Appendix B reviews typical Indala proximity reader connections. Wiring diagrams are on the following pages.
Refer to the appropriate diagram for specific reader connections. Be sure to use a cable that complies with the
reader's wiring specifications.

Power Specifications

The following table outlines Indala reader power specifications:
Reader
PX 603
PX 605
PX 610
PX 620
PXK 501
Installation Notes on Proximity Readers
Do not run reader cables in same conduit with AC power or signal cables.
Keep reader cables at a minimum distance of 12 inches or 30 centimetres from AC, computer data, telephone
data, or electric lock device cables.
Do not install readers within 3.5 feet or 1.1 metres of computer CRTs.
Do not install readers in areas where broad spectrum EMI noise may be present. Devices such as motors,
pumps, generators, and AC switching relays can create EMI noise.
Readers mounted on a metal surface can reduce the read range. See the Indala manual for recommendations.
Keyscan Inc. – Technical Guide (PC109x - 04.15)
Table 21 – Indala Reader Power Specifications
Power
12 VDC, 100 mA
12 VDC, 100 mA
12 VDC, 150 mA
24 VDC, 1.2 A
12 VDC, 80 mA + 20 mA
interface = 100 mA
Notes
Requires additional power supply when connected to CA 8500 circuit
board.
Requires 18 AWG cable.
Connect to separate 24 VDC 2 Amp linear power supply. (Not supplied
with ACU kit.)
Current consumption includes interface circuit board
