Uplift Desk ACC021 Instructions

Package Contents
fig. 1
clamp on
back of desk
!
Read all instructions before assembly. Failure to assemble properly may result in damage.
© UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
Acoustic Privacy Panel
Step 1
On the Acoustic Privacy Panel, before attaching hardware, remove the mate-
rial from the pre-cut holes with your finger or a pencil. You should be able to
see these pre-cut holes near the bottom of the panel.
Remove backing from one side of the Tape pads and attach to support brack-
ets where shown. Then remove backong from other side of the Tape pads.
Step 2
Line up the pegs on the Support bracket with the holes on your Acoustic
Privacy Panel, and push them inside so the Support bracket is flush with the
panel. Press firmly over area with Tape pads.
Step 3
From the other side, line the Clamp bracket up with those holes. Insert the
Flat-head screws and tighten.
Step 4
Loosen both clamps so that the opening is wide enough to slide onto your
desk. The included hardware will fit desktops up to 1.75'' thick.
fig. 2
clamp on Step 5
side of desk
Once on the desk, tighten the clamps onto your desktop (see figure 1).
Note: If you're attaching a Side Acoustic Privacy Panel, make sure the clamps
are tightened onto the desk's bracket (see figure 2).
®
Acoustic Privacy Panel Instructions
ACC021
Mounting Hardware
(comes in box for item
ACC022, separate from
the Privacy screen)
Flat-head
screws
(qty 4)
Clamp Tape
bracket pads
(qty 2) (qty 2)
Support
bracket
(qty 2)
ACC021/R04
