INSTALLATION INSTRUCTIONS

Step 1. Check Package Contents

Missing part? Call 800-264-1190
Mounting hardware kit includes the following:
Part
a.Mounting Brackets
b. Extension Brackets (for outside mounts)
c. Screws
d. Wall Anchors

Step 2. Tools required

Pencil, tape measure, level, screw driver, step stool, drill.

Step 3. Installation

Your blind may be installed either inside the window frame or outside
the window frame.
Wallboard or Plaster: use wall anchors.
Concrete, Stone, Brick: use a masonry drill bit and anchors or
screws specifically designed for masonry (not included).
Inside Mounting:
One bracket should be positioned about 2" to 6" from each end of
the head rail. For wider shades that require 3 or 4 brackets, these
should be spaced evenly between the two outermost brackets.
Attach each bracket to the inner top of the window opening using
the screws provided. Pre-drill the screw holes using a 5/64" drill bit.
The extension brackets are not used for inside mounts.
For flush inside mounts, attach the brackets to the head rail first (see
drawings and attachment instructions below), and then position the
shade in the window opening as desired. Then make pencil marks at
the back of each bracket. Remove the brackets by pressing on the
plastic tab. Align the brackets with the pencil marks, and then screw
them in place as described above.
Outside Mounting:
Attach the Extension Brackets to the wall or window framing. One
bracket should be positioned about 2" to 6" from each end of the
head rail. For wider shades that require 3 or 4 brackets, these should
be spaced evenly between the two outermost brackets. Pre-drill the
screw holes using a 5/64" drill bit.
Quantity
2 for shades up to 45" wide
3 for shades up to 72" wide
2 for shades up to 45" wide
3 for shades up to 72" wide
4 for shades up to 45" wide
6 for shades up to 72" wide
4 for shades up to 45" wide
6 for shades up to 72" wide
3
