SelectBlinds Inside Mount Spring Roller Instructions

The roller shade, when mounted should not make contact with the top of the window frame or any other obstruction when
raised and lowered. Position the mounting brackets inside the window frame. The brackets need to be aligned
and level with one another. When the shade is installed it should move freely between the brackets.
For Standard roll shades install the slotted bracket on the left side of the
window frame and the bracket with the round hole on the right.
For Reverse roll shades install the slotted bracket on the right and the
bracket with the round hole on the left.
The roller shade, when mounted should not make contact with the top of the window frame or any other obstruction when
raised and lowered. Position the mounting brackets outside the window frame. The brackets need to be aligned and level
with one another. When the shade is installed it should move freely between the brackets, be sure to allow 1/8" of
additional space between the brackets so the mechanism will rotate freely.
Spring Roller - Standard Roll
RR641
Attach the mounting brackets to the wall or
window frame with the locking bracket on the
left . These brackets can be used for ceiling
applications by mounting by rotating the foot of
the brackets to the top.
*
Shades with a large diameter rolls will receive an extended version of this bracket (RR642)
Roller Shades Instructions
Spring Roller (Inside Mount)
Spring Roller-Standard Roll
163L
Roller Shades Instructions
Spring Roller (Outside Mount)
*
Spring Roller – Reverse Roll
RR641
Attach the mounting brackets to the wall or
window frame with the locking bracket on the
right . These brackets can be used for ceiling
applications by rotating the foot of the brackets to
the top.
*
