The brackets must be level – use a Spirit Level if necessary to assure
proper alignment.
Then attach a Mounting Bracket to each Extension Bracket using the
nut and bolt pre-attached to each Extension Bracket.
To adjust head rail extension, remove the shade from the mounting
brackets by pressing on the plastic tabs at the front of each bracket.
Then loosen the nut and bolt, and move the mounting brackets
forward or backward as preferred.

Step 4. Securing the Head Rail

Slide the inner rear of the head rail onto the metal tabs at the back of
the brackets, and then push up to lock the head rail in place. Check
carefully to assure that each bracket is properly secured.

Step 5. Attach the Safety Cord Guide

The cord guide must be attached per these instructions in order for
your shade to function properly.
Install Mounting Bracket:
Determine which direction the mounting bracket will face relative to
the Tension Device. Make sure the Tension Device will be snapped
into the mounting stand in the same correct direction. Before
attaching Tension Device to the base, measure and mark the
location in the window where the tension device will be mounted.
Mount the base in position without the tension device attached.
Position the Tension Device on the window frame or the wall so
that the Tension Device and control cord/chain does not interfere
with raising or lowering the shade. The Tension Device should be
installed so that cord/bead chain hangs loosely – do not stretch
or pull down on it. Stretching the cord/bead chain will cause
excessive wear. Do not twist or cross the control cord/bead
chain. In order to position the base properly, adjust the cord so
that the Cord Guide is at the bottom of the cord loop and let it
hang freely. Hold the tension device and the bracket against the
4
