Saso PA-0112 Installation Instructions

Passive Infrared Detector
PA-0112
1. Description & Coverage and Range
COVER (Lens)

2. Cautions on Installation

Please install the detector in the
desirable detection site.

3. Installation (Ceiling)

1) Separate the cover
from body.
4. Wiring & Jumper setting
- TERMINAL
-
+
ALARM
※ Note: PA-0112 is designed for indoor use only. It cannot be used for outdoor.
Notice : This detector is designed to detect an intruder and to sound
alarm when detected; it is not to prevent burglary. We are not
responsible for damage or losses from accident, theft, natural calamity,
misuse, abnormal use, improper installation and bad maintenance.
SENSOR
PCB
Alarm NC/NO
jumper
ALARM
NC
NO
Terminal
BASE
Please avoid installing it where
electric noise and vibration is
prevalent.
2) Fix it where to install.
1 2 3
SENSITIVITY
LED
OFF
ON
ALARM
NC
NO
- SENSITIVITY
High Sensitivity
Low Sensitivity
Installation Instructions
LED
Sensitivity jumper
LED ON/OFF
1 2 3 jumper
SENSITIVITY
LED
OFF
ON
MIRROR PART
Wire entrance
Please avoid direct sunlight to
the detector.
3) Connect wires correctly to
the plate of terminal.
1 2 3
SENSITIVITY
LED
OFF
ON
ALARM
NC
NO
- ALARM
Protection range
Top view
Side view
30°
2.5m
(8.2')
(20')
0
51°
6m
Avoid installing it at outdoor.
(indoor only)
4) Check sensor direction and then
close the body cover.
- LED ON/OFF
NC
NO
84°
7°
(40')
12m
ON
OFF
