Saso -PB10S Installation Instructions

Photoelectric Beam Detector
SASO-PB10S/PB30S/PB60S
1. Description
Response time
Cover
2. Cautions on Installation
Avoid strong light from sun, auto-
mobile head-lights etc. shining on
transmitter or receiver
3. Installation Hints
3-1. Wall mount
① Remove cover from unit
and slide the mounting
plate to detach it.
3-2. Pole mount
(Pole size : Φ38 ~ Φ44mm)
① Remove cover from unit and slide the mounting
plate to detach it.
② Attach pole brackets to pole and secure to mounting
plate with screws plate with screws.
③ Attach sensor body.
④ Pull through wire.
⑤ Connect terminals.
⑥ After wiring is completed, adjust alignment, check
operation and attach cover.
4. Response time
Response time Response time
adjustment
50ms 700ms
Terminals
Good LED
adjustment
Alarm LED
Lens
View finder
Receiver
Do not install the unit on unsteady
surfaces.
② Break grommet on mounting plate
and pull wire through it. Secure
the plate with 4mm screws.
1. Run at full speed 2. Walk with quick steps
(6.9m/s) - 50msec. (1.2m/s) - 200msec.
Please note : This sensor is designed to detect intrusion and to initiate an alarm,
it is not a burglar-preventing device. Maker is not responsible for damage, ,injury
or losses caused by accident, theft, natural disasters, abuse, misuse, abnormal usage,
faulty installation or improper maintenance.
Wiring Hole
Tamper
Power LED
Monitor jack
Vertical
Adjustment screw
Transmitter
Do not install in a site where beam
may be interrupted by trees or
plants, consider seasonal changes.
③ When exposed wired, break knock-
outs on the rear of unit, pull wire
through as the figure and attach it to
the mounting plate.
3. Walking (0.7m/s)
- 300msec.
Installation Instructions
Plate
Do not install in places where units
may be splashed continuously by
dirty water or direct sea spray.
④ After wiring is completed,
adjust alignment, check
operation and attach cover.
4. Walk with slow steps 5~6. Go over a fence(0.3m/s)
(0.5m/s) - 500msec. - 700msec.
