Application Interfaces

3.1. General Description

EG95 is equipped with 62-pin 1.1mm pitch SMT pads plus 44-pin ground/reserved pads that can be
connected to customers' cellular application platforms. Sub-interfaces included in these pads are
described in detail in the following chapters:

Power supply

(U)SIM interfaces

USB interface

UART interfaces

PCM and I2C interfaces

SPI interface

Status indication
