2.2. Before starting the software

When the SONY Corporation RC-S380 NFC reader is used, set up the NFC port following the procedure
below. When the Advanced Card Systems Ltd. ACR1251U/ACR1252U NFC reader is used, the following
setting procedure is not necessary.
(1) The NFC setting on the control panel of your PC must be changed as follows.
Setting: Operate the NFC-B preferentially using the protocol used.
(2) Double-click the [NFC port/PaSoRi] icon on the control panel to display the setting window.
(3) When the setting window is displayed, move [NFC-F], [NFC-A] and [PicoPass] from the card information
indicated on the [Detectable cards] to the [Available cards] selection box using the "Delete" button.
Select the icon.
(Windows7 is used in this Operation Manual)
(Windows7 is used in this Operation Manual)
-8-
Select [NFC-B] only for
[Detectable cards].
No.EX※※-OMV0017-B
