SMC Networks EX600-WPN Operation Manual page 105

(7) Click the "Refresh" button to update the information in the Slave registration window.
(8) Click the radio button for Pairing mode.
(9) Click Yes to change to pairing mode.
(10) Click the "Refresh" button to move to Pairing mode.
(9)
Slave unit registration window (move the wireless master to the Pairing mode)
(11) The Pairing status of the wireless master can be checked by the status indication LED: W-NS. When they
are in pairing mode, the status indication LED: W-NS flashes red and green in turn. When the mode is not
changed to Pairing mode, perform the step (7) to (10) again.
LED in pairing mode (wireless master)
-104-
(7)
(10)
(8)
No.EX※※-OMV0017-B
