Installation and Setup Instructions
for E-Series 60-Drive Trays
E2760 and E5660 controller-drive trays
DE6600 expansion drive trays
Unpack & Prepare
Install Hardware
Connect Drive Trays
Apply Power
Connect Data Hosts
Choose Management Method
Install & Use SANtricity
2 1 0 - 0 6 6 6 5 + A 0
Software
®

Before you begin

Before installing the hardware
Confirm that your location provides 240-volt AC power.
Obtain a standard 19-inch (48.3-cm) rack to fit 4U trays with these dimensions:
Tray Height Width
60-drive 7.00 in. 17.75 in.
(17.78 cm) (45.08 cm)
Install any required host bus adapters (HBAs) in the data hosts as well as any
required switches. Refer to the NetApp Interoperability Matrix at
http://mysupport.netapp.com/matrix
For additional instructions
1 Go to the E-Series and EF-Series Systems Documentation Center:
http://mysupport.netapp.com/eseries.
2 Download these documents from the Getting Started and Installing &
Configuring sections of the page.
Task Document
Preparing your site Site Preparation Guide
Installing a 3040-40U Cabinet Installation Guide
NetApp cabinet
Installing the rails, trays, Controller-Drive Tray and Related Drive Tray
and drives Installation Guide
Cabling the hardware E-Series and EF-Series Hardware Cabling Guide
Choosing a SANtricity Storage Manager Express Guides
management method SANtricity Power Guides for Advanced Users
Installing and using SANtricity Storage Manager Express Guides
SANtricity software SANtricity Power Guides for Advanced Users
For additional help
NetApp Support: http://mysupport.netapp.com/
NetApp Training:
http://www.netapp.com/us/services-support/university/learning.aspx
NetApp Videos: https://www.brainshark.com/go/netapp-sell/library.html
For your safety
Review the Safety Notices document included in the box, and pay close attention
to the precautions for moving and installing hardware.
Depth Max Weight
32.50 in. 236.2 lb
(82.55 cm) (107.1 kg)
for compatibility information.
