Weiser SmartCode 5 Installation And User Manual page 2

3 Install the exterior keypad, mounting plate, and spindle
A
Install exterior keypad.
cable goes
over latch
F
4 Install interior assembly
A
Remove battery cover and battery pack from interior assembly.
a
Remove battery cover.
M
c
Install 4 AA batteries into battery pack.
4x
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
5 Install levers
A
Install interior lever.
Lever handle
faces away
from the latch.
Y1 or Y2
6 Test latch operation
Close door, test latch operation and make adjustments as needed:
The small bolt of the latch should not enter the strike
hole. If it enters the strike hole, reposition strike.
B
Route cable through mounting plate.
G
B
b
Remove K
battery
pack.
Do not install
battery pack
into interior
assembly yet.
B
Secure interior lever.
Tighten pre-
installed set
Z
screw.
small bolt in
strike hole
small bolt NOT
in strike hole
C
Secure mounting plate with
supplied screws.
keep parallel to
edge of door
T (2x)
tighten
screws
evenly
Install interior assembly onto mounting plate.
a
Connect cable.
L
b
K
Install
battery
pack.
C
Install exterior lever.
If latch is loose in the strike, adjust the strike tab so it
grips the latch bolt better when the door is closed.
2 / 4
actual
size
D
Install spindle.
rounded edge
faces latch
F2
latch
Ensure tight cable connection.
c
d
Push interior assembly onto
mounting plate.
Secure with
screws.
Push excess
cable back into
the door as you
install L.
Turnbutton
may need to
be turned to
L
install L.
D
Secure exterior lever.
Lever handle
faces away
from the latch.
Y1 or Y2
tab
T
actual
size
U
U (2x)
Tighten pre-
installed set
Z
screw.
