Dimensions

Overall Width:
E-Series
34 inch Deck
Without Deck 35.6 inches
(90 cm)
Deflector Up 38.5 inches
(98 cm)
Deflector Down 45.9 inches
(117 cm)
S-Series
50 inch Deck
Without Deck 47.9 inches
(122 cm)
Deflector Up 50.6 inches
(129 cm)
Deflector Down 61.7 inches
(157 cm)
Overall Length:
34 inch 42 inch
Deck Deck
75.0 inches 75.0 inches
(191 cm) (191 cm)
Overall Height:
All Units
41.5 inches (105 cm)
Tread Width: (Center to Center of
Tires, Widthwise)
34 inch Deck
Drive Wheels 28.8 inches
(73 cm)
Caster Wheels 29.5 inches
(75 cm)
42 inch Deck
39.0 inches
(99 cm)
45.3 inches
(115 cm)
53.8 inches
(137 cm)
60 inch Deck
47.9 inches
(122 cm)
62.9 inches
(160 cm)
75.2 inches
(191 cm)
50 inch 60 inch
Deck Deck
76.0 inches 76.0 inches
(193 cm) (193 cm)
42 inch Deck
31.5 inches
(80 cm)
29.5 inches
(75 cm)
50 inch Deck
Drive Wheels 39.1 inches
(99 cm)
Caster Wheels 36.9 inches
(94 cm)
Wheel Base: (Center of Caster Tire to
Center of Drive Tire)
34 and 42 inch Decks
50 and 60 inch Decks
Curb Weight:
E-Series
34 inch Deck 42 inch Deck
and 452 cc
Engine
547 lb (248 kg) 496 lb (225 kg)
S-Series
50 inch Deck
752 lb (341 kg)

Torque Requirements

Bolt Location
Spindle Pulley Nut
Blade Mounting Bolt
Engine Mounting Bolts
Wheel Lug Nuts
Clutch Mounting
Bolt (secured with
threadlocker)
17
Specifications
60 inch Deck
39.1 inches
(99 cm)
32.9 inches
(84 cm)
45.6 inches (116 cm)
48.4 inches (123 cm)
42 inch Deck
and 708 cc
Engine
562 lb (255 kg)
60 inch Deck
681 lb (309 kg)
Torque
35-65 ft-lb (47-88 N-m)
35-65 ft-lb (47-88 N-m)
330-400 in-lb (37-45 N-m)
70-90 ft-lb (95-122 N-m)
50-60 ft-lb (68-81 N-m)
