Loose Parts

Use the chart below to verify that all parts have been shipped. Part numbers not shown are available on the dealer
extranet.
Dealer Pack
Part #
Literature Pack
Part #

Model and Required Bagger Blades

Model Number
109-9764: Fits 48 and 52 inch Quest decks.
Required Bagger Blades
109-6391 — Fits 48 inch Quest decks
109-6392 — Fits 52 inch Quest decks

Assembly Diagrams

Key
1
2
3
4
5
6
7
8
9
10
11
12
© 2007–2008—Exmark Mfg. Co., Inc.
P.O. Box 808
Beatrice, NE 68310
Description
Warranty Registration Form
Description
Manual, Operator's
Manual, Parts
Qty.
1
Qty.
1
Read before operating the machine.
1
Qty
Description
1
Asm, Hood Bagger
1
Asm, Upper Tube
1
Asm, Lower Tube
1
Rod, Weight Lock
1
Weight, Bagger 35#
10
Nut, Nyloc 3/8-16 Flg
2
Screw, Button Head 3/8-16 x 1
1
Asm, Bracket and Bumpers
4
Plate, Stiffener
4
Bolt, Carriage 3/8-16 x 5
2
Plate, Stiffener
2
Tube, Hitch
QUEST
BAGGER
®
Setup Instructions
For Serial Nos. 752,000 & Higher
Use
Use
Part No. 4500-263 Rev. A
Printed in the USA.
All Rights Reserved
