Rice Lake 520 Installation Manual page 68

SETPTS Menu
Parameter Choices
RELNUM 1–8
BATCH OFF
ON
PSHACCM OFF
ON
ONQUIET
PSHPRNT OFF
ON
WAITSS
PSHTARE OFF
ON
ALARM OFF
ON
START 1–8
END 1–8
ACCESS ON
HIDE
OFF
NAME NONE, 1–8
DIGOUT NONE, 1–4
RELSP setpoints: Specifies the number of the relative setpoint. The target weight for
this setpoint is:
• For +RELSP, the value of the relative setpoint plus the value (VALUE parameter) of
this setpoint
• For –RELSP, the value of the relative setpoint minus the value of this setpoint
• For %RELSP, the percentage (specified on the VALUE parameter for this setpoint)
of the relative setpoint
GROSSSP, NETSP, and RELSP setpoint types: Specifies whether the setpoint is
used as a batch (ON) or continuous (OFF) setpoint.
GROSSSP, NETSP, RELSP, PAUSE, DELAY, and WAITSS setpoint types: Specify ON
to update the accumulator and perform a print operation when the setpoint is
satisfied. Specify ONQUIET to update the accumulator without printing.
GROSSSP, NETSP, RELSP, PAUSE, DELAY, and WAITSS setpoint types: Specify ON
to perform a print operation when the setpoint is satisfied; specify WAITSS to wait for
standstill after setpoint is satisfied before printing.
GROSSSP, NETSP, RELSP, PAUSE, DELAY, and WAITSS setpoint types: Specify ON
to perform an acquire tare operation when the setpoint is satisfied. NOTE: PSHTARE
acquires the tare regardless of the value specified for the REGULAT parameter on the
PROGRM menu.
GROSSSP, NETSP, RELSP, DELAY, and WAITSS setpoint types: Specify ON to
display the word ALARM on the primary display while the setpoint is active (batch
setpoints) or while the setpoint is not tripped (continuous setpoints).
TIMER and CONCUR setpoint types: Specifies the starting setpoint number. Do not
specify the number of the TIMER or CONCUR setpoint itself. The TIMER or
CONCUR setpoint begins when the starting setpoint begins.
TIMER and CONCUR setpoint types: Specifies the ending setpoint number. Do not
specify the number of the TIMER or CONCUR setpoint itself. The TIMER or
CONCUR setpoint stops when the ending setpoint begins.
All setpoint types: Specifies whether or not the setpoint can be accessed in weigh
mode via the front panel entry mode.
ON: Value can be displayed and changed
HIDE: Value cannot be displayed or changed
OFF: Value can be displayed but not changed
Setpoints with ACCESS=ON can be turned on or off when a batch is not running:
• To turn the setpoint on/off, enter front panel setup mode (push and hold UNITS
key). Select setpoint by pressing UNITS or PRINT (
pressing GROSS/NET ( ).
All setpoint types: Specify the number of an assigned prompt. Up to 8 prompt
names can be specified on the PROMPTS submenu of the PROGRM menu.
All setpoint types: Specifies a digital output associated with the setpoint. For
continuous setpoints, the digital output becomes active (low) when the condition is
met; for batch setpoints, the digital output is active until the setpoint condition is met.
Table 12-2. Setpoint Menu Parameters (Continued)
Description
or ). Turn setpoint on/off by
Setpoints 63
