Kind
CONCUR Allows a digital output to remain active over a specified portion of the batch
sequence. Two types of concur setpoints can be configured:
Type 1 (VALUE=0):
active when the START setpoint becomes the current batch step and remains
active until the END setpoint becomes the current batch step.
Type 2 (VALUE > 0):
value represents the timer, in tenths of a second, for this setpoint. The digital
output associated with this setpoint becomes active when the START setpoint
becomes the current batch step and remains active until the timer expires.
NOTE: If more than one concurrent setpoint is configured, each must be
assigned to a different digital output.
SETPTS Menu
Parameter Choices
Level 3 submenus
GROSSSP VALUE
NETSP TRIP
+RELSP BANDVAL
–RELSP HYSTER
%RELSP PREACT
PREVAL
RELNUM
BATCH
PSHACCM
PSHTARE
PSHPRNT
ALARM
ACCESS
NAME
DIGOUT
PAUSE PSHTARE
DELAY PSHPRNT
WAITSS PSHACCM
ACCESS
DIGOUT
NAME
VALUE
COUNTER VALUE
AUTOJOG ACCESS
COZ NAME
INMOTON DIGOUT
INRANGE
–GROSS
–NET
BATCHPR
TIMER VALUE
CONCUR START
END
ACCESS
NAME
DIGOUT
Description
The digital output associated with this setpoint becomes
If a non-zero value is specified for the VALUE parameter, that
Table 12-1. Setpoint Kinds (Continued)
Configure GROSSSP, NETSP, and RELSP setpoints. See Figure 3-12 on page 31
and Level 4 parameter descriptions.
Configure PAUSE, DELAY, and WAITSS setpoints. See Figure 3-13 on page 32 and
Level 4 parameter descriptions.
Configure COUNTER, AUTOJOG, COZ, INMOTON, INRANGE, –GROSS, –NET,
AND BATCHPR setpoints. See Figure 3-14 on page 32 and Level 4 parameter
descriptions.
Configure TIMER and CONCUR setpoints. See Figure 3-15 on page 32 and Level 4
parameter descriptions.
Table 12-2. Setpoint Menu Parameters
Batch
Description
Continuous
√
Setpoints 61
