Translating ASCII Status Data
Use the table at right to evaluate the ASCII character
output for bytes 3 – 12 and determine which of the
low order bits are set on.
For example, if the Digital Output Status returned in
bytes 8 – 11 is AC@@, the table at right can be used
with the bit assignments described above to
determine that digital outputs 4, 7, and 8 are active:
• A (byte 8) indicates that DIGOUT 4 (bit 0) is on
• C (byte 9) indicates that DIGOUTs 7 and 8 (bits 1
and 0) are on
• @@ indicates that bytes 10 and 11 are not used
ASCII Value
Table 10-15. ASCII Translation Table for BATSTATUS Data
Bit 3 Bit 2
@ 0
A 0
B 0
C 0
D 0
E 0
F 0
G 0
H 1
I 1
J 1
K 1
L 1
M 1
N 1
O 1
Bit 1 Bit 0
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
EDP Commands
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
